![Optimus Drive PDM20-2S1R5 Руководство по эксплуатации онлайн [23/54] 473996](/views2/1762412/page23/bg17.png)
PDM20 Series
- 22 -
Function
code
Description Set range Unit Default
Display
level
Modific
ation
level
Notes
P0.15
Self-starting
delay at power
on
0.0～
100.0
s 5.0 ○
Delay time before
auto-start at power on
P0.16 Antifreeze
0：OFF
1：ON
0 ○
Self anti-freezing
function of pump
P0.17
Anti-freezing
running
frequency
0.0～
60.00
Hz 8.00 1 ○
P0.18
Anti-freezing
running time
0～9999
s 60 1 ○
P0.19
Anti-freezing
running cycle
0～9999 s 300 1 ○
When it is set as 0, it
keeps running at
anti-freezing running
frequency
P0.20
Water leakage
coefficient
0.0～
100.0
2.0 ○
The bigger the water
leakage, the bigger the
coefficient.
P0.21
Set value of
high pressure
alarm
0.0～
P0.03
bar 8.0 ○
When feedback pressure
is bigger than or equal to
the set value, after the
delay of P0.22, it alarms
and stops.
P0.22
Detection time
of high
pressure alarm
0.0～
200.0
s 3.0
P0.23
Set value of
low pressure
alarm
0.0～
P0.21
bar 0.0 ○
When feedback pressure
is smaller than the set
value, after the delay of
P0.24, it alarms and
stops. This function is
invalid when it is set to
0.
P0.24
Detection time
of low
pressure alarm
0.0～
200.0
s 3.0 ○
