PDM20 Series
- 25 -
Function
code
Description Set range Unit Default
Display
level
Modific
ation
level
Notes
P0.40
Current fault
type
0～29
○
0：No fault
1：Inverter unit
protection（E001）
2：Over current in
acceleration（E002）
3：Over current in
deceleration（E003）
4：Over current at
constant speed（E004）
5：Over voltage in
acceleration（E005）
6：Over voltage in
deceleration（E006）
7：Over voltage at
constant speed（E007）
8：Hardware
overvoltage（E008）
9：Under voltage fault
（E009）
10：SPD overload（E010
）
11：Motor overload（
E011）
12：Reserved
13
：Output phase loss
（E013）
14：Radiator
overheating（E014）
15：External water
shortage（E015）
16～17：Reserved
18：Current detection
fault（E018）
19～21：Reserved
22：EEPROM fault（
E022）
