PDM20 Series
- 24 -
Function
code
Description Set range Unit Default
Display
level
Modific
ation
level
Notes
P0.30
Self-restarting
delay of water
shortage
protection
0～9999
min 15 1 ○
If it is set to be 0, use
pressure to self-reset
water shortage.
P0.31 Self-sleep rate
1～30
3 1 ○
Increase this value when
the system can’t sleep.
P0.32
Inflow
detection
pressure
0.0～
P0.00
bar 1.0 1 ○
After inflow pressure is
larger than detection
pressure time
(P0.33),water shortage
fault is automatically
reset.
P0.33
Inflow
detection time
0.0～
100.0
s 1.0 1 ○
P0.34
Lower limit of
AI
0.0～
P0.35
V/mA 4.00 ○
P0.35
Upper limit of
AI
P0.34～
20.00
V/mA 20.00 ○
P0.36
Acceleration
time
0.1～
3600
s 5.0 ○
P0.37
Deceleration
time
0.1～
3600
s 3.0 ○
P0.38
Parameter
initialization
0～2 0 0
●
0：No operation
1：Reset to factory
defaults
2：Clear fault records
P0.39
Parameter
lock
0～1
0 ○
If it is set to be1, P1
group parameters will
be hidden.
