19
Guide Line up
P. 3–4, 7–8
Outdoor units
P. 33–34
Options
P. 58
Outer dimension drawings
P. 61
Remote controllers
P. 35–36
Standard specifications
P. 40 and 50
Fits in ceiling corners.
Equipped for versatile
airflow control.
Wired LCD remote controller
Note: R emote controller c able not
included. C ables must be proc ured
locally.
Accessory required for indoor unit
(option)
BRC1C61
Note: Air direc tion is s et to the standard pos ition when the unit is s hipped from
the factory. The position c an be changed from the remote controller.
Multiple airflow variations
for stepped or 3.8 m high ceilings
Switchable fan speed:
High/Low
Programme "Dry"
Dehumidification is microprocessor controlled to prevent
abrupt and uncomfortable changes in air temperature.
High ceiling
installation
Air dis charge grille, flexible duct
R equires ceiling tap c utting. R equires ceiling tap c utting. Not s uited for high c eilings
because air c urrents do not
Optimal comfort and convenience assured by three air discharge modes
Air direction
Desired
situation
Auto-swing
5-levels
air direction
setting
Draft prevention
(In heating)
model
Auto air
direction control
S ettable to 5 different
levels between 0° and 65°
S ettable to 5 different
levels between 30° and 65°
S ettable to 5 different
levels between 40° and 65°
When drafts are unwanted For gentle drafts
(Ceiling is soiled.)
When ceilings must
be kept spotless
Draft prevention setting
Standard setting
Setting to prevent soiling of ceiling
At heating startup and thermo O FF*,
air discharge is automatically s et to
a near horizontal 10˚ to prevent di-
rect exposure to cool air drafts.
3
2
1
1 2 3 4 5 6
3.8
(m)
2.0
m/s
1.5
m/s
0.5
m/s
0.3
m/s
1.0
m/s
3
2
1
1 2 3 4 5 6
(m)
2.0
m/s
1.5
m/s
0.5
m/s
0.3
m/s
1.0
m/s
Air c onditioner
C over here with
dec orative panel.
Dec orative panel
(s old s eparately)
Downward flow
Downward flow + Forward flow
Forward flow
Wind speed profile
Heating
(65° downward flow
...
Standard installation)
Wind speed profile
Heating
(65° downward flow from high ceiling)
E x a m ple ins t a lla tio ns
On stepped ceiling
(Outward
+
downward flow)
In the corner of a room
(downward flow)
On stepped ceilings, downward flow
can be blocked and outward flow alone
can be used to cool or heat the space.
Decorative panels (option) can be in-
stalled on the downward air discharge
opening to close gaps without stepped
room interiors.
Auto-swing
Required options
1 2 3
Auto-swing between
0° and 65°
Auto-swing between
0° and 65°
Auto-swing between
0° and 65°
Airflow
variation
Comfortable cooling from
ceiling to floor
(downward flow)
The air direction is s et automatically to the memoris ed posi-
tion of the previous air direction. (Initial s etting is 65° for
heating and 30° for c ooling.)
Panel spacers (option) can be installed with all three airflow variations.
Decoration panels (option) to hide the downward air discharge opening can be installed with variation above.
3
CEILING MOUNTED CASSETTE CORNER TYPE
Quiet operation
Easier to install and service
Drain pump is equipped as
standard accessory with
500
mm
lift.
Indoor unit High Low
35F(J)
39 33
45F(J)
39 34
60F(J)
41 36
71F(J)
41 36
500
mm
P a n e l s pa c e r ( opt ion )
Use when only minimal space is
available between drop ceilings and
ceiling slabs.
For outward blow, detach the punch-out
panel from the duct-connection port on
the front of the unit.
Low gas pressure detection
Long-life filter lasts about 1 year *
Maintenance not required
* For dust concentration of 0.15 mg/m
3
Fresh air intake possible
(Site installation required)
A duct can be connected to the rear of the
indoor unit to draw in outdoor air.
Note: The maximum duc t length for connec tion to
the fres h air intake kit is 5 m. C onnecting
ducts, insect nets, fire dampers , air filters,
and other parts should, as required, be
Upgrade options for easy
installation on stepped ceilings
Air disc harge grille Flexible duc t
20
*When the thermostat turns off.
CEILING MOUNTED
CASSETTE CORNER
TYPE
FH
(
Y
)
K
FH(Y)K35FV1–71F(J)V1Cooling only
FHYK35FJV1–71FJV1Heat pump
FHYK71FJ
On stepped ceiling
(outward
+
downward flow)
Features (Features are explained on P. 37–38.)
Mould
prevention
Comfort Work & Servicing Control features
Others
*3
*3
*3
*3
*2
*1
Feature
Model
Heat pump
Cooling only
*
1
Applicable to R71LU outdoor units (for temp. down to – 15°C ) (An option is required.)
*
2
Applicable to RY71LU outdoor units (for temp. down to – 5°C )
*
3
Applicable to R(Y)71LU outdoor units
Auto s wing
Draft prevention func tion
S wing pattern selec tion
S witchable fan speed
Programme "Dry"
High c eiling application
Hot start
Year-round c ooling
applicable
Timer s elec tor
Mould resis tant
treatment for filter
Drain pump mechanis m
Pre charged for
up to 30 m
Long-life filter
Filter sign
C eiling soiling prevention
Low gas press ure
detec tion
E mergenc y operation
S elf-diagnosis func tion
Auto-restart
Auto-cooling/heating
change-over
C ontrol by 2 remote
controllers
C ontrol by 1 remote
controller
E xternal c ommand
control
C entral remote c ontrol
Interlock control
PE fin
K eep duct no more than 5 m long.
Panel s pac er
C eiling
20mm
Note : Anechoic c hamber conversion value,
measured ac cording to J IS parameters and
41
/
36
dB(A)
FHYK71FJ
High Low
Sound level
dB(A)
