ED42-019A Specifications
FD-K Series 7
4.2 60Hz
R-FU Series <60Hz>
Note: 1. ∗1 The above data are based on the following conditions.
Capacities are gross capacities which do not include a deduction for indoor fan motor heat.
Model
Indoor Unit FD03KVAL FD04KVAL FD05KTAL
Outdoor Unit R71FUVAL R100FUVAL R125FUTAL
∗1 Cooling Capacity (1)/(2)/(3)
kW 8.6 / 8.5 / 7.1 12.1 / 11.9 / 9.0 15.5 / 15.2 / 14.1
Btu/h 29,400 / 29,000 / 24,200 41,300 / 40,600 / 30,700 52,800 / 52,000 / 48,100
kcal/h 7,400 / 7,300 / 6,100 10,400 / 10,200 / 7,700 13,300 / 13,100 / 12,100
Indoor Unit FD03KVAL FD04KVAL FD05KTAL
Dimensions H×W×D mm 450×650×850 450×900×850 450×900×850
Coil
Type Cross Fin Coil (Waffle Louver Fins and Hi-XA Tubes)
Row×Stages×Fin Pitch 2×24×2.0 2×24×2.0 2×24×2.0
Face Area m² 0.238 0.370 0.370
Fan
Type Sirocco Fan
Drive Belt Drive
Motor Output kW 0.4 0.4 0.75
Air Flow Rate
m³/min 26 30 46
cfm 917 1,059 1,623
Ext. Static Pressure
mmH
2
O
799
Weight kg 54 62 72
Piping Connections
Liquid mm φ 9.5 (Brazing) φ 9.5 (Brazing) φ 9.5 (Brazing)
Gas mm φ 15.9 (Brazing) φ 19.1 (Brazing) φ 19.1 (Brazing)
Drain mm FPS3/4B FPS3/4B FPS3/4B
Remote Controller
Wired KRC47-3 KRC47-3 KRC47-3
Wireless — — —
Outdoor Unit R71FUVAL R100FUVAL R125FUTAL
Color Ivory
Dimensions H×W×D mm 816×880×370 1,215×880×370 1,215×880×370
Coil
Type Cross Fin Coil
Row×Stages×Fin Pitch 2×36×2.0 2×54×2.0 2×54×2.0
Face Area m² 0.653 0.979 0.979
Comp.
Model H23A35QABCA H23A46QABCA H23A62QDBLA
Type Hermetically Sealed Type
Motor Output kW 3.4 4.5 6.0
Fan
Model P45J11SM P45J11SM×2 P45J11SM×2
Type Propeller
Motor Output W 80 90+60 90+80
Air Flow Rate
m³/min 55 92 98
cfm 1,941 3,247 3,459
Weight kg 87 117 110
Piping Connections
Liquid mm φ 9.5 (Flare) φ 9.5 (Flare) φ 9.5 (Flare)
Gas mm φ 15.9 (Flare) φ 19.1 (Flare) φ 19.1 (Flare)
Drain mm φ 26.0 (Hole) φ 26.0 (Hole) φ 26.0 (Hole)
Safety Devices
Thermal Protector for Outdoor Fan Motor.
Internal Pressure Relief Valve (Compressor).
Motor Protector (Compressor). Over Current Relay for Indoor Fan Motor.
Capacity Step % 100 – 0 100 – 0 100 – 0
Refrigerant Control Capillary Tube
Ref. Piping
Standard Length m 5 5 5
Max. Length m 50 (Equivalent Length 70m) 50 (Equivalent Length 70m) 50 (Equivalent Length 70m)
Max. Height Difference m 30 30 30
Refrigerant
Model R22 R22 R22
Charge kg
2.2
(Factory Charge for 5m)
2.9
(Factory Charge for 5m)
3.1
(Factory Charge for 5m)
Ref. Oil
Model SUNISO 3GS
Charge L 1.48 1.63 1.63
Drawing No. C : 4D008260A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length Standard
(1)
Indoor:
Outdoor:
27°C(81°F)DB, 19.5°C(67°F)WB
35°C(95°F)DB
5m (Horizontal) —
(2)
Indoor:
Outdoor:
27°C(81°F)DB, 19.0°C(66°F)WB
35°C(95°F)DB
5m (Horizontal) —
(3)
Indoor:
Outdoor:
29°C(84°F)DB, 19.0°C(66°F)WB
46°C(115°F)DB, 24°C(75°F)WB
7.5m (Horizontal) SSA 385/386
