Daikin FD10KY1 [12/104] Ed42 019a specifications
![Daikin FD04KY1 [12/104] Ed42 019a specifications](/views2/1764827/page12/bgc.png)
ED42-019A Specifications
FD-K Series 9
RU-KU Series <60Hz>
Note: 1. ∗1 The above data are based on the following conditions.
Capacities are gross capacities which do not include a deduction for indoor fan motor heat.
Model
Indoor Unit FD08KTAL FD10KTAL FD15KTAL FD20KTAL
Outdoor Unit RU08KUTAL RU10KUTAL RU08KUTAL×2 RU10KUTAL×2
∗1 Cooling Capacity (1)/(2)/(3)
kW 24.3 / 24.0 / 21.9 29.7 / 29.2 / 26.7 48.6 / 47.9 / 43.8 59.3 / 58.4 / 53.3
Btu/h 83,000 / 81,800 / 74,600 101,200 / 99,600 / 91,300 166,000 / 163,500 / 149,500 202,400 / 199,400 / 182,000
kcal/h 20,900 / 20,600 / 18,800 25,500 / 25,100 / 23,000 41,800 / 41,200 / 37,700 51,000 / 50,200 / 45,800
Indoor Unit FD08KTAL FD10KTAL FD15KTAL FD20KTAL
Dimensions H×W×D mm 500×1,130×850 500×1,330×850 625×1,620×850 625×1,980×850
Coil
Type Cross Fin Coil (Waffle Louver Fins and Hi-XA Tubes)
Row×Stages×Fin Pitch 3×22×2.0 3×22×2.0 3×26×2.0 3×26×2.0
Face Area m² 0.443 0.540 0.784 0.990
Fan
Type Sirocco Fan
Drive Belt Drive
Motor Output kW 1.5 1.5 2.2 3.7
Air Flow Rate
m³/min 68 83 136 166
cfm 2,400 2,930 4,800 5,860
Ext. Static Pressure
mmH
2
O
10 10 15 15
Weight kg 93 104 161 187
Piping Connections
Liquid mm φ 12.7 (Brazing) φ 15.9 (Brazing) 2× φ 12.7 (Brazing) 2× φ 15.9 (Brazing)
Gas mm φ 25.4 (Brazing) φ 31.8 (Brazing) 2× φ 25.4 (Brazing) 2× φ 31.8 (Brazing)
Drain mm FPS3/4B FPS3/4B FPS1B FPS1B
Remote Controller
Wired KRC47-3 KRC47-3 KRC17-2B KRC47-3 KRC17-2B KRC47-3
Wireless————
Outdoor Unit RU08KUTAL RU10KUTAL RU08KUTAL×2 RU10KUTAL×2
Color Ivory White
Dimensions H×W×D mm 1,220×1,280×690 1,440×1,280×690 2×(1,220×1,280×690) 2×(1,440×1,280×690)
Coil
Type Cross Fin Coil (Waffle Louver Fins and Hi-XA Tubes)
Row×Stages×Fin Pitch 2×40×2.0 2×50×2.0 2×(2×40×2.0) 2×(2×50×2.0)
Face Area m² 1.57 1.97 2×1.57 2×1.97
Comp.
Model JT236D-P1 JT300D-P1 2×(JT236D-P1) 2×(JT300D-P1)
Type Hermetically Sealed Scroll Type
Motor Output kW 5.5 7.5 2×5.5 2×7.5
Fan
Model P52H11S P52H11S 2×P52H11S 2×P52H11S
Type Propeller
Motor Output W 230+190 230+190 2×(230+190) 2×(230+190)
Air Flow Rate
m³/min 160 190 2×160 2×190
cfm 5,648 6,707 2×5,648 2×6,707
Weight kg 185 200 2×185 2×200
Piping Connections
Liquid mm φ 12.7 (Flare) φ 15.9 (Flare) 2× φ 12.7 (Flare) 2× φ 15.9 (Flare)
Gas mm φ 25.4 (Brazing) φ 31.8 (Brazing) 2× φ 25.4 (Brazing) 2× φ 31.8 (Brazing)
Drainmm————
Safety Devices
Thermal Protector for Compressor and Outdoor Fan Motor.
High Pressure Switch. Low Pressure Switch. Over Current Relay (Compressor and Indoor Fan Motor).
Reverse Phase Protector. Fuse.
Capacity Step % 100 – 0 100 – 0 100 – 50 – 0 100 – 50 – 0
Refrigerant Control Capillary Tube
Ref. Piping
Standard Length m 5 5 5 5
Max. Length m 50 (Equivalent Length 70m) 50 (Equivalent Length 70m) 50 (Equivalent Length 70m) 50 (Equivalent Length 70m)
Max. Height Difference m 30 30 30 30
Refrigerant
Model R22 R22 R22 R22
Charge kg
5.0
(Factory Charge for 5m)
6.1
(Factory Charge for 5m)
2×5.0
(Factory Charge for 5m)
2×6.1
(Factory Charge for 5m)
Ref. Oil
Model SUNISO 4GSDID-K
Charge L 4.0 4.0 2×4.0 2×4.0
Drawing No. C : 4D045869 C : 4D045871
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length Standard
(1)
Indoor:
Outdoor:
27°C(81°F)DB, 19.5°C(67°F)WB
35°C(95°F)DB
5m (Horizontal) —
(2)
Indoor:
Outdoor:
27°C(81°F)DB, 19.0°C(66°F)WB
35°C(95°F)DB
5m (Horizontal) —
(3)
Indoor:
Outdoor:
29°C(84°F)DB, 19.0°C(66°F)WB
46°C(115°F)DB, 24°C(75°F)WB
7.5m (Horizontal) SSA 385/386
