ED42-019A Power Supply and Nomenclature
FD-K Series 1
1. Power Supply and Nomenclature
1.1 Power Supply
Note: 1. ∗ : New Model or Changed Model
2. Power Supply Intake; Outdoor Unit
1.2 Nomenclature
Indoor Unit
Outdoor Unit
Symbol Indoor Unit Outdoor Unit Power Supply
Y1
FD03KY1 R71FUY1
3φ 380~415V 50Hz
(4 wires)
FD04KY1 R100FUY1
FD05KY1 R125FUY1
FD06KY1 RU06KY1
FD08KY1 RU08KY1
FD08KY1 RU08KUY1
∗
FD10KY1 RU10KY1
FD10KY1 RU10KUY1
∗
FD15KY1 RU08KY1×2
FD15KY1 RU08KUY1×2
∗
FD20KY1 RU10KY1×2
FD20KY1 RU10KUY1×2
∗
VAL
FD03KVAL R71FUVAL
1φ 220V 60Hz
FD04KVAL R100FUVAL
TAL
FD05KTAL R125FUTAL
3φ 220V 60Hz
FD06KTAL RU06KTAL
FD08KTAL RU08KTAL
FD08KTAL RU08KUTAL
∗
FD10KTAL RU10KTAL
FD10KTAL RU10KUTAL
∗
FD15KTAL RU08KTAL×2
FD15KTAL RU08KUTAL×2
∗
FD20KTAL RU10KTAL×2
FD20KTAL RU10KUTAL×2
∗
Duct Connection High Static Pressure Type
FD : Cooling Only
Capacity : HP
Indicates Major Design Category
Power Supply Symbol
Y103FD K
Y1 : 3φ 380~415V 50Hz
VAL : 1φ 220V 60Hz
TAL : 3φ 220V 60Hz
Outdoor Unit
R, RU : Cooling Only
Capacity ×100 kcal/h (50 Hz)
Indicates Major Design Category
Power Supply Symbol
Y171R FU
K
KU
FU
50Hz 60Hz
Y1 : 3φ 380~415V 50Hz
VAL : 1φ 220V 60Hz
TAL : 3φ 220V 60Hz
