Specifications ED42-019A
8 FD-K Series
RU-K Series <60Hz>
Note: 1. ∗1 The above data are based on the following conditions.
Capacities are gross capacities which do not include a deduction for indoor fan motor heat.
Model
Indoor Unit FD06KTAL FD08KTAL FD10KTAL FD15KTAL FD20KTAL
Outdoor Unit RU06KTAL RU08KTAL RU10KTAL RU08KTAL×2 RU10KTAL×2
∗1 Cooling Capacity (1)/(2)/(3)
kW 17.4 / 17.3 / 15.7 24.3 / 24.0 / 21.9 29.7 / 29.2 / 26.7 48.6 / 47.9 / 43.8 59.3 / 58.4 / 53.3
Btu/h
59,500 / 59,100 / 53,600 83,000 / 81,800 / 74,600
101,200 / 99,600 / 91,300 166,000 / 163,500 / 149,500 202,400 / 199,400 / 182,000
kcal/h
15,000 / 14,900 / 13,500 20,900 / 20,600 / 18,800 25,500 / 25,100 / 23,000 41,800 / 41,200 / 37,700 51,000 / 50,200 / 45,800
Indoor Unit FD06KTAL FD08KTAL FD10KTAL FD15KTAL FD20KTAL
Dimensions H×W×D mm 450×1,130×850 500×1,130×850 500×1,330×850 625×1,620×850 625×1,980×850
Coil
Type Cross Fin Coil (Waffle Louver Fins and Hi-XA Tubes)
Row×Stages×Fin Pitch 2×24×2.0 3×22×2.0 3×22×2.0 3×26×2.0 3×26×2.0
Face Area m² 0.491 0.443 0.540 0.784 0.990
Fan
Type Sirocco Fan
Drive Belt Drive
Motor Output kW 0.75 1.5 1.5 2.2 3.7
Air Flow Rate
m³/min 52 68 83 136 166
cfm 1,835 2,400 2,930 4,800 5,860
Ext. Static Pressure
mmH
2
O
9 10101515
Weight kg 79 93 104 161 187
Piping Connections
Liquid mm φ 9.5 (Brazing) φ 12.7 (Brazing) φ 15.9 (Brazing) 2× φ 12.7 (Brazing) 2× φ 15.9 (Brazing)
Gas mm φ 19.1 (Brazing) φ 25.4 (Brazing) φ 31.8 (Brazing) 2× φ 25.4 (Brazing) 2× φ 31.8 (Brazing)
Drain mm FPS3/4B FPS3/4B FPS3/4B FPS1B FPS1B
Remote Controller
Wired KRC47-3 KRC47-3 KRC47-3
KRC17-2B
KRC47-3
KRC17-2B
KRC47-3
Wireless — — — — —
Outdoor Unit RU06KTAL RU08KTAL RU10KTAL RU08KTAL×2 RU10KTAL×2
Color Ivory White
Dimensions H×W×D mm 1,345×880×320 1,220×1,280×690 1,440×1,280×690 2×(1,220×1,280×690) 2×(1,440×1,280×690)
Coil
Type Cross Fin Coil (Waffle Louver Fins and Hi-XA Tubes)
Row×Stages×Fin Pitch 2×26×2.0 2×40×2.0 2×50×2.0 2×(2×40×2.0) 2×(2×50×2.0)
Face Area m² 1.16 1.57 1.97 2×1.57 2×1.97
Comp.
Model JT190B JT236D-P1 JT300D-P1 2×(JT236D-P1) 2×(JT300D-P1)
Type Hermetically Sealed Scroll Type
Motor Output kW 4.5 5.5 7.5 2×5.5 2×7.5
Fan
Model P45J11SM P52H11S P52H11S 2×P52H11S 2×P52H11S
Type Propeller
Motor Output W 100+100 230+190 230+190 2×(230+190) 2×(230+190)
Air Flow Rate
m³/min 108 160 190 2×160 2×190
cfm 3,812 5,648 6,707 2×5,648 2×6,707
Weight kg 112 176 188 2×176 2×188
Piping Connections
Liquid mm φ 9.5 (Flare) φ 12.7 (Brazing) φ 15.9 (Brazing) 2× φ 12.7 (Brazing) 2× φ 15.9 (Brazing)
Gas mm φ 19.1 (Flare) φ 25.4 (Brazing) φ 31.8 (Brazing) 2× φ 25.4 (Brazing) 2× φ 31.8 (Brazing)
Drain mm — — — — —
Safety Devices
Thermal Protector for
Compressor and
Outdoor Fan Motor.
High Pressure Switch.
Low Pressure Switch.
Over Current Relay
(Compressor and
Indoor Fan Motor).
Reverse Phase
Protector. Fuse.
Thermal Protector for Compressor and Outdoor Fan Motor.
High Pressure Switch. Over Current Relay (Compressor and Indoor Fan Motor).
Reverse Phase Protector. Fuse.
Capacity Step % 100 – 0 100 – 0 100 – 0 100 – 50 – 0 100 – 50 – 0
Refrigerant Control Capillary Tube
Ref. Piping
Standard Length m 5 5 5 5 5
Max. Length m
50 (Equivalent Length
70m)
50 (Equivalent Length
70m)
50 (Equivalent Length
70m)
50 (Equivalent Length
70m)
50 (Equivalent Length
70m)
Max. Height Difference m 30 30 30 30 30
Refrigerant
Model R22 R22 R22 R22 R22
Charge kg
3.0
(Factory Charge
for 5m)
5.0
(Field Charge
for 5m)
6.1
(Field Charge
for 5m)
2×5.0
(Field Charge
for 5m)
2×6.1
(Field Charge
for 5m)
Ref. Oil
Model SUNISO 4GSDID-K
Charge L 1.6 4.0 4.0 2×4.0 2×4.0
Drawing No. C : 4D006820A C : 4D008678
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length Standard
(1)
Indoor:
Outdoor:
27°C(81°F)DB, 19.5°C(67°F)WB
35°C(95°F)DB
5m (Horizontal) —
(2)
Indoor:
Outdoor:
27°C(81°F)DB, 19.0°C(66°F)WB
35°C(95°F)DB
5m (Horizontal) —
(3)
Indoor:
Outdoor:
29°C(84°F)DB, 19.0°C(66°F)WB
46°C(115°F)DB, 24°C(75°F)WB
7.5m (Horizontal) SSA 385/386
