Pr 02 50 200 Medium grill turnspit according to the model Q Selecting this function switches on the central upper heating element for direct radiation of heat over food This function must be used between 50 to 200 C Pre set value 200 C 50 200 Large grill turnspit according to the model R Selecting this function switches on the two upper heating elements for direct radiation of heat over food This function must be used between 50 to 200 C Pre set value 200 C 50 260 Medium Fan assisted Grill The air warmed up by the grill element medium is pumped by the fan which then conveys it onto the food This function guarantees good results with poultry sausages and red meat This function must be used between 50 to 200 C Pre set value 200 C 50 200 Fan assisted total grill The air which is heated by the grill heating element is circulated by the fan and so helps to distribute the heat The fan assisted grill replaces perfectly the turnspit You can obtain very good results also with large quantities of poultry sausage red meat This function must be used between 50 to 200 C Pre set value 200 C 50 260 Natural convection Both the lower and upper heating elements operate together This is the traditional cooking very good for roasting joints ideal for biscuits baked apples and crisping food You obtain very good results when cooking on a shelf adjusting the temperature between 50 and 260 C pre set value 180 C 50 260 Fan oven Both the fan and the circular heating element operate together The hot air adjustable between 50 and 260 C is evenly distributed inside the oven This is ideal for cooking several types of food meat fish at the same time without affecting taste and smell It is indicated for delicate pastries Pre set value 170 C 50 260 Fan assisted natural convection Both the top and bottom elements are on as is the fan This is the conventional cooking method excellent for a variety of foods It produces good results for cooking on one level ideal for biscuits cakes and canapés with the temperature adjustable from 50 to 260 C Pre set value 185 C 50 260 Fan with lower heating element The air warmed up by the lower heating element is pumped by the fan which then conveys it onto the food at a temperature of between 50 and 260 C This function is good for sterilising foods pre set value 220 C 50 260 Turning on the oven s top heating element It can be used to reheat cooked food by placing the oven rack on the second level from the top or to defrost bread pizza or pasta by placing the oven rack on the first level from the bottom This function works at temperatures of between 50 and 260 C Pre set value 220 C 50 260 Fan with top heating element The air warmed up by the top heating element is pumped by the fan which then conveys it onto the food at a temperature of between 50 and 260 C Pre set value 220 C 50 260 Fan oven energy saving function The fan and circular heating element are on at the same time Hot air temperature of between 50 and 260 C is conveyed uniformly on all levels This function is ideal for cooking different types of food meat or fish for a long time Pre set value 170 C Pr 03 Pr 04 Pr 05 Pr 06 Pr 07 Pr 08 Pr 09 Pr10 Pr11 Pr 12 35
