COOLING MOTOR
Some models are equipped with tangential cooling motor.
NOTE: Install the grids, by placing them on the horizontal slides inside
the oven wall.
The raised part of the grid must be in face of the oven rear
wall
(fig. 6).
Use of the turnspit .
- Thread the chicken or the cubes of meat for
roasting on below spit L, ensuring that it is
gripped safely between the two forks F (fig. 6A
- 6B).
- Put the spit on support G, .
- Put support G completely into the oven.
- Fit the end of the spit into the motor M at the
back of the oven
- Place the oven tray with a little water on the
lowest shelf of the oven.
- Close the oven door.
- Turn the knob to position grill ( - -
according to the models) to start up the motor.
- When removing the spit, wear oven mitts and
pull out support G.
The turnspit is an optional available only in some
models.
Centrale turnspit see figure. 6A.
Diagonal turnspit see figure. 6B.
DESCRIPTIONS OF ACCESSORIES
TURNSPIT (optional)
front part
Oven accessories
A = wire shelves B = Drip dray (optional) D = Grill pan set
fig. 6
AB C
F
L
G
M
fig. 6B
M
F
L
G
fig. 6A
38
