GB 10
Pressing"Extra"on the timer display allows you to select the Wi-
Fi menu. In the Wi-Fi menu if you pressthe "< >" buttonsyou can select:
- Off: Wi-Fi is off; the oven is not controllablevia the app.
- On: Wi-fi is on and the oven is only controllable via the app. It means that it is not possible to select cooking
functions, recipes and temperature from the display. Only the Wi-Fi menu is available by pressing "Extra". You
can switch the oven off using the On/Off button, but you cannot switch it back on again via the display, it can
only be switched on via the app.
- Reset: This setting should be used to enrol the oven the first time it connects to your Wi-Fi network and to
reset the current Wi-Fi connection to allow a new enrolment. Once selected, the appliance gives you 5
minutes to complete the enrolment process. During this process the cooking functions, recipes and
temperature setting are not accessible from the display. Only the Wi-Fi menu is available by pressing "Extra".
You can switch the oven off using the On/Off button, but you cannot switch it back on again via the display, it
can only be switched on via the app. To exit the enrolment/reset procedure via the display, press "Extra" and
then use "< >" buttons to select "Off". After five minutes, the appliance will exit the enrolment/reset
procedure automatically.
- Read: the oven sends its status to the app but it cannot be controlled remotely. The oven must be enrolled
before this is possible.
If Wi-Fi is not configured it is only possible to choose between off and reset.
When the oven is connected to Wi-Fi, the default cooking time duration is 5 hours, but this can be modified by
the user.
Wi-Fi Enrolment:
To enroll the appliance for Wi-Fi, press "Extra" on the display until the Wi-Fi icon lights, then select "Reset" by
pressing "< >". The procedure on the app should then be followed. Once selected, the appliance gives you 5
minutesto complete the enrolmentprocess.
Wi-Fi icon
- Icon not lit: Wi-Fi is off.
- Icon blinks 1 second on an 1 second off:the oven is accessible to your Wi-Fi network and readyto be enrolled.
If the enrolmenthas not been successful, the Wi-Fi iconwill switchoffafter 5 minutes.
- Icon is permanently lit: the oven is connected to your Wi-Fi router.
- The icon blinks 3 seconds on and 1 second off: the oven is trying to connect to your Wi-Fi router.
- The icon blinks 1 second on and 3 seconds off: the ovenis in read only mode.
WiFi (depends on the oven model)
Grill
Oven box
Turnspit
Circular
heating element
Bottom heating element
Fan
Defost
Pyro
LANGUAGE SETTING The language can be set when
the oven is switched off by pressing the Extra and Select
buttonssimultaneouslyand for 3". The current language is
shown on the display and can be changed by pressing the
“<” or “>” keys, confirming it by pressing SELECT. Available
languagesare: Italian,English, French and German.
SELECT Any selection must be confirmed. If not
confirmed within 15 seconds, the selection is cancelled.
Bychanging menu, any unconfirmed selection is lost.
“HOT” ICON When a cooking programme finishes or when the oven switches off, if the oven is still
hot, the display showsthe currenttime alternating with the message “HOT” at 3 intervals.
CANDY SIMPLY-FI:
For detailed information about HOW TO CONNECT your simply-Fi appliance and
HOW TO USE it at its best, go to or visit the dedicatedhttp://www.candysimplyfi.com
simply-Fi Customer Service website http://simplyfiservice.candy-hoover.com
