32
PRIME/PRO/ProArt/TUF GAMING Intel 400 Series BIOS Manual
Max. CPU Graphics Ratio
This item allows you to configure the CPU graphics ratio. The ratio may vary depending on
the system loading.
Configuration options: [Auto] [1] - [23]
Extreme Over-voltage
This item can only be enabled when the onboard CPU_OV jumper is switched on. Setting
this item to [Enabled] allows you to configure higher voltages for overclocking, but the CPU
lifetime will not be guaranteed.
Configuration options: [Disabled] [Enabled]
CPU Core/Cache Voltage
Configures the mode of Voltage fed to the cores of the processor.
Configuration options: [Auto] [Manual Mode] [Offset Mode]
The following item appears only when CPU Core/Cache Voltage is set to [Manual
Mode].
CPU Core Voltage Override
Allows you to configure the CPU Core voltage.
Configuration options: [Auto] [0.600] - [1.700]
The following items appear only when CPU Core/Cache Voltage is set to [Offset Mode].
Offset Mode Sign
[+] To offset the voltage by a positive value.
[–] To offset the voltage by a negative value.
CPU Core Voltage Offset
CPU Core Voltage Offset
This item allows you to configure the input voltage for the CPU by the external voltage
regulator.
Configuration options: [Auto] [-0.635] - [0.635]
DRAM Voltage
Configuration options: [Auto] [1.000] - [2.000]
CPU VCCIO Voltage
Configuration options: [Auto] [0.900] - [1.800]
CPU System Agent Voltage
Configuration options: [Auto] [0.700] - [1.750]
PLL Termination Voltage
Configuration options: [Auto] [0.800] - [1.600]
CPU Graphics Voltage Mode
This item allows you to configure the mode of voltage fed to the CPU Graphics. Manual
mode allows user-defined values. Offset mode modifies values by SVID.
Configuration options: [Auto] [Manual Mode] [Offset Mode]
