ASUS PRIME H310M-D R2.0

1-3

DDR4 DIMM slots

Install2GB,4GB,8GB,and16GBunbufferednon-ECCDDR4DIMMsintothese

DIMMsockets.

Formoredetails,refertoSystem memory.

Intel

H310 Serial ATA 6.0Gb/s connectors (7-pin SATA6G_1~4)

TheseconnectorsconnecttoSerialATA6.0Gb/sharddiskdrivesviaSerialATA

6.0Gb/ssignalcables.

Speaker connector (4-pin SPEAKER)

The4-pinconnectorisforthechassis-mountedsystemwarningspeaker.The

speakerallowsyoutohearsystembeepsandwarnings.

System panel connector (10-1 pin F_PANEL)

Thisconnectorsupportsseveralchassis-mountedfunctions.

Clear RTC RAM (2-pin CLRTC)

ThisheaderallowsyoutocleartheCMOSRTCRAMdataof

thesystemsetupinformationsuchasdate,time,andsystem

passwords.

To erase the RTC RAM:

1. TurnOFFthecomputerandunplugthepowercord.

2. Useametalobjectsuchasascrewdrivertoshortthetwo

pins.

3. PlugthepowercordandturnONthecomputer.

4. Holddownthe<Del>keyduringthebootprocessand

enterBIOSsetuptore-enterdata.

CLRTC

+3V_BAT

GND

PIN 1

Ifthestepsabovedonothelp,removetheonboardbatteryandshortthetwopinsagain

tocleartheCMOSRTCRAMdata.AfterclearingtheCMOS,reinstallthebattery.

USB 3.1 Gen 1 (up to 5Gbps)connector (20-1 pin U31G1_12)

ConnectaUSB3.1Gen1moduletothisconnectorforadditionalUSB3.1

Gen1frontorrearpanelports.ThisconnectorcomplieswithUSB3.1Gen1

specicationsandprovidesfasterdatatransferspeedsofupto5Gbps,faster

chargingtimeforUSB-chargeabledevices,optimizedpowerefciency,and

backwardcompatibilitywithUSB2.0.

USB 2.0 connector (10-1 pinUSB910)

ConnectaUSBmodulecabletothisconnector,theninstallthemoduletoaslot

openingatthebackofthesystemchassis.ThisUSBconnectorcomplieswithUSB

2.0specicationsandsupportsupto480Mbpsconnectionspeed.
