![Asus PRIME H310M-D R2.0/CSM [7/27] Prime h310m d r2 specifications summary](/views2/1769355/page7/bg7.png)
vii
PRIME H310M-D R2.0 specications summary
USB
Intel
®
H310 Chipset:
- 4 x USB 3.1 Gen 1 (up to 5Gbps) ports (2 ports at mid-board; 2 ports at back
panel, blue, Type-A)
- 6 x USB 2.0/1.1 ports (2 ports at mid-board; 4 ports at back panel)
LAN Realtek
®
8111H Gigabit LAN supports LANGuard
Audio
Realtek
®
ALC887 8-channel High Denition Audio CODEC*
- LED-illuminated design: Brighten up your build with the gorgeous illuminated audio
trace path
- Audio Shielding: Ensures precision analog/digital separation and greatly reduces
multi-lateral interference
- Dedicated audio PCB layers: Separate layers for left and right channels to guard the
quality of the sensitive audio signals
- Premium Japanese audio capacitors: Provide warm, natural and immersive sound
with exceptional clarity and delity
- Supports jack-detection and front panel jack-retasking
* Choose the chassis with HD audio module in front panel to support an 8-channel audio
output.
ASUS
special
features
ASUS 5X PROTECTION III
- ASUS SafeSlot Core - Fortied PCIe Slot prevents damage
- ASUS LANGuard - Protects against LAN surges, lightning strikes and static -
electricity discharges
- ASUS Overvoltage Protection - World-class circuit-protecting power design
- ASUS Stainless-Steel Back I/O - 3x corrosion-resistance for greater durability
- ASUS DIGI+ VRM - 4 phase digital power design
Superb Performance
ASUS OptiMem
- Improved DDR4 stability
M.2 onboard
- The latest transfer technologies with up to 10Gb/s data transfer speeds
ASUS EPU
- EPU
UEFI BIOS
- The most advanced options with a fast response time
Gaming Scenario
Audio features
- Audio that roars on the battleeld
ASUS Exclusive Features
- ASUS AI Charger
- ASUS AI Suite 3
- ASUS PC Cleaner
(continued on the next page)
