![Asus PRIME H310M-D R2.0/CSM [6/27] Check your motherboard package for the following items](/views2/1769355/page6/bg6.png)
vi
PRIME H310M-D R2.0 specications summary
Package contents
Check your motherboard package for the following items.
Motherboard
ASUS PRIME H310M-D R2.0 motherboard
Cables
2 x Serial ATA 6.0 Gb/s cables
Accessories
1 x I/O Shield
1 x M.2 Anchor
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.
CPU
LGA1151 socket for Intel
®
8th Generation Core™ i7 / i5 / i3, Pentium
®
, and Celeron
®
processors
Supports Intel
®
14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset
Intel
®
H310 Chipset
Memory
2 x DIMMs, maximum 32GB, DDR4 2666/2400/2133 MHz, non-ECC, un-buffered
memory
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* The maximum memory frequency supported varies by processor.
** DDR4 2666MHz and higher memory modules will run at maximum 2666MHz on Intel
®
8th
Generation 6-core or higher processors.
*** Refer to www.asus.com for the Memory QVL (Qualied Vendors List).
Expansion
slots
1 x PCI Express 3.0/2.0 x16 slot (at x16 mode)
2 x PCI Express 2.0 x1 slots
Graphics
Integrated graphics processor - Intel
®
HD Graphics support
Multi-VGA output support: HDMI/D-Sub ports
- Supports HDMI 1.4b with maximum resolution of 4096 x 2160 @24Hz / 2560 x
1600@60Hz
- Supports D-Sub with maximum resolution of 1920 x 1200 @60Hz
Supports Intel
®
InTru™ 3D/Quick Sync Video/Clear Video HD Technology/Insider™
Maximum shared memory of 1024MB
Storage
Intel
®
H310 Chipset:
- 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support
(SATA mode & x2 PCIe mode)*
- 4 x SATA 6.0 Gb/s ports (gray)
* When a device in SATA mode is installed on the M.2 socket, SATA_2 port cannot be used.
** Due to the Chipset limitation, when an M.2 device is installed in PCIe mode, the socket is
set to PCIe 2.0.
(continued on the next page)
