Asus PRIME H310M-D R2.0/CSM [8/27] Prime h310m d r2 specifications summary
![Asus PRIME H310M-D R2.0/CSM [8/27] Prime h310m d r2 specifications summary](/views2/1769355/page8/bg8.png)
viii
PRIME H310M-D R2.0 specications summary
Specications are subject to change without notice.
ASUS special
features
EZ DIY
UEFI BIOS EZ Mode
- Featuring a friendly graphics user interface
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
ASUS Q-Design
- ASUS Q-DIMM
ASUS quiet
thermal
solution
Quiet Thermal Design
- ASUS Fan Xpert
- Stylish Fanless Design: PCH heatsink solution
Rear panel I/O
ports
1 x PS/2 keyboard / mouse combo port
2 x USB 3.1 Gen 1 (up to 5Gbps) ports (Type-A, blue)
4 x USB 2.0/1.1 ports
1 x HDMI port
1 x D-Sub port
1 x LAN (RJ-45) port
1 x LPT port
1 x COM port
3 x Audio jacks support 8-channel audio output*
* Choose the chassis with HD audio module in front panel to support an 8-channel audio
output.
Internal
connectors
1 x USB 3.1 Gen 1 (up to 5Gbps) connector supports additional 2 USB 3.1 Gen 1
ports (19-pin)
1 x USB 2.0/1.1 connectors support additional 2 USB 2.0/1.1 ports
4 x SATA 6.0Gb/s connectors
1 x M.2 Socket3 (for M Key)
1 x 4-pin CPU Fan connector for 4-pin PWM mode
1 x 4-pin Chassis Fan connector for 3-pin (DC mode) and 4-pin (PWM mode)
coolers control
1 x Front panel audio connector (AAFP)
1 x S/PDIF Out connector
1 x Speaker connector
1 x 24-pin EATX Power connector
1 x 4-pin ATX 12V Power connector
1 x System panel connector
1 x Clear CMOS jumper (2-pin)
BIOS features
128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-
language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Qfan Control, F3 My
Favorites, Last Modied log, F12 PrintScreen, and ASUS DRAM SPD (Serial
Presence Detect) memory information
Manageability
WOL by PME, PXE
Support DVD
Drivers
ASUS utilities
Anti-virus software (OEM version)
OS support
Windows
®
10 (64-bit)
Form factor
uATX form factor: 8.9 in. x 7.3 in. (22.6 cm x 18.5 cm)
