Asus PRIME H310M-D R2.0/CSM [13/27] Rear panel connectors

ASUS PRIME H310M-D R2.0

1-5

5. Line In port (light blue).Thisportconnectstothetape,CD,DVDplayer,orother

audiosources.

LAN port

Speed

LED

Activity Link

LED

Activity/Link LED Speed LED

Status Description Status Description

Off Nolink OFF 10Mbpsconnection

Orange Linked ORANGE 100Mbpsconnection

Orange

(Blinking)

Dataactivity GREEN 1Gbpsconnection

Orange

(Blinkingthen

steady)

Readytowake

upfromS5mode

1. PS/2 mouse/keyboard combo port.ThisportconnectstoaPS/2mouseorPS/2

keyboard.

2. LPT port.Thisportsupportsdevicessuchasaprinter.LPTstandardizesasIEEE

1284,whichistheparallelportinterfaceonIBMPC-compatiblecomputers.

3. USB 3.1 Gen 1 (up to 5Gbps) ports.These9-pinUniversalSerialBus(USB)ports

areforUSB3.1Gen1devices.

• USB3.1Gen1devicescanonlybeusedfordatastorage.

• WestronglyrecommendthatyouconnectUSB3.1Gen1devicestoUSB3.1Gen1

portsforfasterandbetterperformancefromyourUSB3.1Gen1devices.

• DuetothedesignoftheIntel

300serieschipset,allUSBdevicesconnectedtothe

USB2.0andUSB3.1Gen1portsarecontrolledbythexHCIcontroller.Somelegacy

USBdevicesmustupdatetheirrmwareforbettercompatibility.

4. LAN (RJ-45) port.ThisportallowsGigabitconnectiontoaLocalAreaNetwork(LAN)

throughanetworkhub.

 LAN port LED indications

Rear panel connectors

1 2

5 6

91011
