5-48
Chapter 5: BIOS Setup
ECC Configuration
DRAM ECC Symbol Size [Auto]
Configuration options: [x4] [x8] [x16] [Auto]
DRAM ECC Enable [Auto]
This option allows you to enable or disable DRAM ECC. Auto will set ECC
to enable.
Configuration options: [Disabled] [Enabled] [Auto]
DRAM ECC Enable [Auto]
This option allows you to enable or disable DRAM UECC Retry.
Configuration options: [Disabled] [Enabled] [Auto]
Security
TSME [Auto]
Configuration options: [Disabled] [Enabled] [Auto]
Data Scramble [Auto]
Configuration options: [Disabled] [Enabled] [Auto]
DRAM Memory Mapping
Chipselect Interleaving [Auto]
This item allows you to set interleave memory blocks across the DRAM chip selects for
node 0.
Configuration options: [Disabled] [Auto]
BankGroupSwap [Auto]
Configuration options: [Enabled] [Disabled] [Auto]
BankGroupSwapAlt [Auto]
Configuration options: [Enabled] [Disabled] [Auto]
Address Hash Bank [Auto]
This item allows you to enable or disable bank address hashing.
Configuration options: [Enabled] [Disabled] [Auto]
Address Hash CS [Auto]
This item allows you to enable or disable CS address hashing.
Configuration options: [Enabled] [Disabled] [Auto]
Address Hash RM [Auto]
This item allows you to enable or disable RM address hashing.
Configuration options: [Enabled] [Disabled] [Auto]
SPD Read Optimization [Auto]
This item allows you to enable or disable SPD Read Optimization, if set to [Enabled],
SPD reads are skipped for Reserved fields and most of upper 256 Bytes. If set to
[Disabled], read all 512 SPD Bytes.
Configuration options: [Enabled] [Disabled] [Auto]
