Si04-807 Specifications
Specifications 7
50Hz 230V
Note:
The data are based on the conditions shown in the table below.
Model
Indoor Units FTK35GV1B
Outdoor Units RK35GV1B
Capacity
Rated (Min.~Max.)
kW 3.2 (1.3~3.8)
Btu/h 10,900 (4,400~13,000)
kcal/h 2,750 (1,120~3,270)
Running Current (Rated) A 5.0
Power Consumption
Rated (Min.~Max.)
W 950 (290~1,300)
Power Factor % 82.6
COP
Rated (Min.~Max.)
W/W 3.37 (4.48~2.92)
Piping
Connections
Liquid mm
φ
6.4
Gas mm
φ
9.5
Drain mm
φ
18.0
Heat Insulation Both Liquid and Gas Pipes
Max. Interunit Piping Length m 15
Max. Interunit Height Difference m 12
Chargeless m 10
Amount of Additional Charge
of Refrigerant
g/m 20
Indoor Unit FTK35GV1B
Front Panel Color White
Airflow Rate
m³/min
(cfm)
H 9.3 (328)
M 7.7 (272)
L 6.1 (215)
SL 4.9 (173)
Fan
Type Cross Flow Fan
Motor Output W 16
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18
Power Consumption (Rated) W 40
Power Factor % 96.6
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 283×770×198
Packaged Dimensions (H×W×D) mm 263×840×344
Weight kg 7
Gross Weight kg 11
Operation
Sound
H/M/L/SL dBA 41/34/27/23
Sound Power H dBA 57
Outdoor Unit RK35GV1B
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 1YC23AEXDA
Motor Output W 750
Refrigerant
Oil
Model FVC50K
Charge L 0.375
Refrigerant
Model R-410A
Charge kg 1.0
Airflow Rate
(H)
m³/min 27.6
cfm 975
Fan
Type Propeller
Motor Output W 33
Running Current (Rated) A 4.82
Power Consumption (Rated) W 910
Power Factor % 82.1
Starting Current A 5.0
Dimensions (H×W×D) mm 550×658×275
Packaged Dimensions (H×W×D) mm 616×788×359
Weight kg 30
Gross Weight kg 33
Operation
Sound
HdBA 48
Sound Power H dBA 62
Drawing No. 3D059075
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
5m
