Specifications Si04-807
8 Specifications
1.2 Heat Pump
50Hz 230V
Note:
The data are based on the conditions shown in the table below.
Model
Indoor Units FTX20GV1B FTX25GV1B
Outdoor Units
RX20GV1B RX25GV1B
Cooling Heating Cooling Heating
Capacity
Rated (Min.~Max.)
kW 2.0 (1.3~2.6) 2.5 (1.3~3.5) 2.5 (1.3~3.0) 2.8 (1.3~4.0)
Btu/h 6,800 (4,400~8,900) 8,500 (4,400~1,1600) 8,500 (4,400~10,200) 9,600 (4,400~13,600)
kcal/h 1,720 (1,120~2,240) 2,150 (1,120~3,010) 2,150 (1,120~2,580) 2,410 (1,120~ 3,440)
Running Current (Rated) A 2.7 3.0 3.7 3.5
Power Consumption
Rated (Min.~Max.)
W 550 (310~720) 640 (250~950) 740(310~1,050) 760 (250~1,110)
Power Factor (Rated) % 88.6 92.8 87.0 94.4
COP
Rated (Min.~Max.)
W/W 3.62 (4.19~3.61) 3.90 (5.2~3.68) 3.38 (4.19~2.86) 3.68 (5.2~3.60)
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 15 15
Max. Interunit Height Difference m 12 12
Chargeless m 10 10
Amount of Additional Charge
of Refrigerant
g/m 20 20
Indoor Unit FTX20GV1B FTX25GV1B
Front Panel Color White White
Airflow Rate
m³/min
(cfm)
H 9.1 (321) 9.4 (331) 9.2 (325) 9.7 (342)
M 7.4 (261) 7.8 (276) 7.6 (268) 8.0 (283)
L 5.9 (208) 6.3 (222) 6.0 (212) 6.3 (222)
SL 4.7 (166) 5.5 (194) 4.8 (169) 5.5 (194)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 16 16
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18 0.18 0.18
Power Consumption (Rated) W 40 40 40 40
Power Factor % 96.6 96.6 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 283×770×198 283×770×198
Packaged Dimensions (H×W×D) mm 263×840×344 263×840×344
Weight kg 7 7
Gross Weight kg 11 11
Operation
Sound
H/M/L/SL dBA 39/33/25/22 39/34/28/25 40/33/26/22 40/34/28/25
Sound Power H dBA 55 55 56 56
Outdoor Unit RX20GV1B RX25GV1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AEXDA 1YC23AEXDA
Motor Output W 750 750
Refrigerant
Oil
Model FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant
Model R-410A R-410A
Charge kg 0.74 0.74
Airflow Rate
(H)
m³/min 29.2 26.2 29.2 26.2
cfm 1,030 927 1,030 927
Fan
Type Propeller Propeller
Motor Output W 33 33
Running Current (Rated) A 2.52 2.82 3.52 3.32
Power Consumption (Rated) W 510 600 700 720
Power Factor % 88.0 92.5 86.5 94.3
Starting Current A 2.7 3.7
Dimensions (H×W×D) mm 550×658×275 550×658×275
Packaged Dimensions (H×W×D) mm 616×788×359 616×788×359
Weight kg 28 28
Gross Weight kg 31 31
Operation
Sound
H dBA 46 47 46 47
Sound Power H dBA 60 61 60 61
Drawing No. 3D059070 3D059071
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
5m
