Model No.DLM460 460MM CORDLESS LAWN MOWER

Item Parts No. Description I/C Qty New/Old Opt. 1 Opt. 2 Note

072 140F06-3 DRUM HOLDER COMPLETE 1

073 922438-8 H.S.H.BOLT M8X22 WITH WR 1

074 347506-0 BRAKE DRUM 1

075 327207-6 SPINDLE 1 *

075-1 327361-6 SPINDLE < 1

076 911221-8 PAN HEAD SCREW M5X16 2

077 922116-0

HEX. SOCKET HEAD BOLT

M4X12

078 253874-0 FLAT WASHER 4 1

079 266420-0 TAPPING SCREW 5X20 4

080 319768-0 MOTOR BRACKET 1 *

080-1 319908-0 MOTOR BRACKET < 1

081 911243-8 PAN HEAD SCREW M5X25 4

082 140F51-8 BRAKE COVER COMPLETE 1

󳢢󳢢󳢢󳢢C10 211326-7 BALL BEARING 6004DDW 1 *

󳢢󳢢󳢢󳢢C11 210237-3 BALL BEARING 6004DDW O 1

083 911243-8 PAN HEAD SCREW M5X25 4

084 266326-2 TAPPING SCREW 4X18 2

085 687124-5 STRAIN RELIEF 1

086 266326-2 TAPPING SCREW 4X18 2

087 632M81-0 LEAD UNIT 1

088 620939-7 CONTROLLER 1

089 422351-5 SPONGE 2

090 458799-5 COWLING LOWER 1

091 922438-8 H.S.H.BOLT M8X22 WITH WR 4

092 266326-2 TAPPING SCREW 4X18 2

093 183K40-0 TERMINAL HOUSING SET 1

󳢢󳢢󳢢󳢢C10 263005-3 RUBBER PIN 6 4

󳢢󳢢󳢢󳢢D10 INC. 97

094 266326-2 TAPPING SCREW 4X18 3

095 644809-6 TERMINAL 2

096 854V26-4 DLM460 SERIAL NO. LABEL 1

097 183K40-0 TERMINAL HOUSING SET 1

󳢢󳢢󳢢󳢢C10 263005-3 RUBBER PIN 6 4

󳢢󳢢󳢢󳢢D10 INC. 93

098 266326-2 TAPPING SCREW 4X18 2

099 458797-9 SWITCH COVER 1

100 422350-7 SPONGE 1

101 688163-8 LINE FILTER 1

102 651083-9 SWITCH C3XA-1PSPM 1

103 458808-0 BUFFLE PLATE 1

104 266326-2 TAPPING SCREW 4X18 4

105 140F05-5 BLADE SUPPORT COMPLETE 1

Please order the parts with part number. Print Date 26/3/2020
