Model No.DLM460 460MM CORDLESS LAWN MOWER

Item Parts No. Description I/C Qty New/Old Opt. 1 Opt. 2 Note

106 199367-2 BLADE 460 SET 1

113 941251-5 FLAT WASHER 10 1

114 921556-9 HEX. BOLT M10X35 1

115 DA00001252 REAR FLAP 1 *

115-1 DA00001295 REAR COVER O 1

116 818A77-5 CAUTION LABEL 1

118 671660001 MULCHING PLUG BOX 1

119 671316004 LOCKING BUTTON 1

120 671011005 COMPRESSION SPRING 1

121 671317001

PRESSING BOARD OF

LOCKING

122 DA00000603 TAPPING SCREW ST4X16 2

123 DA00000562 HEX.FLANGE BOLT M8X16 2

124 DA00001248 HANDLE BRACKET R 1

125 DA00000543 HEX.FLANGE LOCK NUT M6 1

126 671009017 STOP RING E-6 1

127 671001518 REAR FLAP HINGE ROD 1

128 671011101 REAR FLAP TORSION SPRING 1

129 671009017 STOP RING E-6 1

130 DA00000543 HEX.FLANGE LOCK NUT M6 1

131 DA00000537 HEX.FLANGE LOCK NUT M8 2

132 DA00001249 HANDLE BRACKET L 1

133 DA00000562 HEX.FLANGE BOLT M8X16 2

134 671002019 TRUSS HEAD SCREW M6X12 2

135 DA00000787

HEIGHT ADJUSTER STOP

PLATE

1 *

135-1 459361-9 ADJUST PLATE < 1

136 DA00000543 HEX.FLANGE LOCK NUT M6 2

137 DA00000537 HEX.FLANGE LOCK NUT M8 2

138 DA00001250 DECK 1 *

138-1 DA00001294 DECK O 1

139 671011125

HEIGHT ADJUST TENSION

SPRING

140 DA00001154 LINK ROD 1

141 DA00000549

NYLON INSERT HEX.LOCK

NUT M6

142 DA00000549

NYLON INSERT HEX.LOCK

NUT M6

143 671800104 GROMMET 1 *

144 818A76-7 3 IN 1 LOGO LABEL 1

145 DA00000536 WHEEL COVER 7 INCH 1

146 DA00000537 HEX.FLANGE LOCK NUT M8 1

147 DA00000538 BALL BEARING 6201ZZ 1

148 671020160 WHEEL ASSY 8 INCH 1

149 DA00000538 BALL BEARING 6201ZZ 1

Please order the parts with part number. Print Date 26/3/2020
