Sirius SL 107 [13/16] Схема подключения sltc em107
![Sirius SL 107 [13/16] Схема подключения sltc em107](/views2/1772767/page13/bgd.png)
13
СХЕМА ПОДКЛЮЧЕНИЯ
SLTC - EM107
КОНДЕНСАТОР
ТОЛЬКО ДЛЯ ВНЕШНЕГО МОТОРА
ВНЕШНИЙ МОТОР
ТРАНСФОРМАТОР
СВЕТОДИОД СВЕТОДИОД
ТОЛЬКО ДЛЯ ВНЕШНЕГО
МОТОРА SEM7
жёлтый / зелёный
голубой
белый
жёлтый
красный
коричневый
чёрный
