Daikin RXM25N2V1B9 [10/55] 3 capacity and power input
![Daikin RXM25N2V1B9 [10/55] 3 capacity and power input](/views2/1772908/page10/bga.png)
• Outdoor Unit • RXM-N9
2
• Split - Sky Air • RXM-N9
8
2 Specifications
Notes
See separate drawing for electrical data
See separate drawing for operation range
Nominal cooling capacities are based on: indoor temperature: 27°CDB, 19°CWB, outdoor temperature: 35°CDB, equivalent refrigerant piping: 5m, level difference: 0m.
Nominal heating capacities are based on: indoor temperature: 20°CDB, outdoor temperature: 7°CDB, 6°CWB, equivalent refrigerant piping: 5m, level difference: 0m.
Power consumption in
other than active
mode
Off mode Cooling POFF kW 14.0 0.014 0.015
Heating POFF kW 14.0 0.014 0.015
Standby mode Cooling PSB kW 14.0 0.014 0.015
Heating PSB kW 14.0 0.014 0.015
Thermostat-off
mode
Cooling PTO kW 7.0 0.007 0.009
Heating PTO kW 7.0 0.007 0.009
Space heating (Warm
climate)
Energy efficiency class A+++ A++ A+
Capacity Pdesignh kW 1.40 1.57 2.13 2.48
SCOP 5.38 4.88 4.40 4.47
SCOPnet 5.46 4.95 4.45 4.51
Annual energy consumption kWh/a 365 450 679 777
Required back up heating cap at design
conditions
kW 0.00
TOL Tol (temperature
operating limit)
°C -15
Pdh (declared
heating cap)
kW 1.93 2.15 3.59 3.72
COPd (declared COP) 2.20 2.01 1.89 1.91
Power input kW 0.88 1.07 1.90 1.95
TBivalent Tbiv (bivalent
temperature)
°C 2
Pdh (declared
heating cap)
kW 1.40 1.57 2.13 2.48
COPd (declared COP) 4.21 3.84 4.10 3.92
Power input kW 0.33 0.41 0.52 0.63
B Condition (2°C) Pdh (declared
heating cap)
kW 1.40 1.57 2.13 2.48
COPd (declared COP) 4.21 3.84 4.10 3.92
Power input kW 0.33 0.41 0.52 0.63
C Condition (7°C) Pdh (declared
heating cap)
kW 1.00 1.02 1.62
COPd (declared COP) 5.54 4.94 4.56 4.52
Power input kW 0.18 0.21 0.36
D Condition (12°C) Pdh (declared
heating cap)
kW 1.17 1.19 1.92
COPd (declared COP) 6.84 6.08 5.49 5.46
Power input kW 0.17 0.20 0.35
2-3 Capacity and Power input FVXM25F/RXM25N9 FVXM35F/RXM35N9 FVXM50F/RXM50N9
Indoor unit FVXM25FV1B FVXM35FV1B FVXM50FV1B
Outdoor unit RXM25N2V1B9 RXM35N2V1B9 RXM50N2V1B9
Cooling capacity Min. kW 1.30 1.40
Btu/h 4,435 4,776
kcal/h 1,117 1,203
Nom. kW 2.50 3.50 5.00
Btu/h 8,530 11,943 17,061
kcal/h 2,150 3,009 4,299
Max. kW 3.00 3.80 5.60
Btu/h 10,236 12,966 19,107
kcal/h 2,579 3,267 4,815
2-2 Capacity and Power input FDXM25F9/RXM25N9 FDXM35F9/RXM35N9 FDXM50F9/RXM50N9 FDXM60F9/RXM60N9
