• Split - Sky Air • RXM-N9
11
• Outdoor Unit • RXM-N9
2 Specifications
Notes
See separate drawing for electrical data
See separate drawing for operation range
Nominal cooling capacities are based on: indoor temperature: 27°CDB, 19°CWB, outdoor temperature: 35°CDB, equivalent refrigerant piping: 5m, level difference: 0m.
Nominal heating capacities are based on: indoor temperature: 20°CDB, outdoor temperature: 7°CDB, 6°CWB, equivalent refrigerant piping: 5m, level difference: 0m.
Power consumption in
other than active
mode
Thermostat-off
mode
PTO Cooling W 8.0
Heating W 8.0
Off mode POFF W 2.0
Standby mode Cooling PSB W 2.0
Heating PSB W 2.0
Space heating (Warm
climate)
Capacity Pdesignh kW 1.29 1.56 2.27
Energy efficiency class A+++ A++
SCOP 5.81 5.44 4.96
SCOPnet 5.93 5.52 5.01
Annual energy consumption kWh/a 311 402 641
Required back up heating cap at design
conditions
kW 0.00
TOL Tol (temperature
operating limit)
°C -15
Pdh (declared
heating cap)
kW 2.09 2.12 3.96
COPd (declared COP) 2.24 1.94 1.82
Power input kW 0.93 1.09 2.18
TBivalent Tbiv (bivalent
temperature)
°C 2
Pdh (declared
heating cap)
kW 1.29 1.56 2.27
COPd (declared COP) 4.39 4.03 4.32
Power input kW 0.29 0.39 0.53
B Condition (2°C) Pdh (declared
heating cap)
kW 1.29 1.56 2.27
COPd (declared COP) 4.39 4.03 4.32
Power input kW 0.29 0.39 0.53
C Condition (7°C) Pdh (declared
heating cap)
kW 0.83 1.03 1.80
COPd (declared COP) 5.79 5.11 5.13
Power input kW 0.14 0.20 0.35
D Condition (12°C) Pdh (declared
heating cap)
kW 0.78 1.08 1.91
COPd (declared COP) 7.27 7.24 6.25
Power input kW 0.11 0.15 0.31
2-4 Capacity and Power input FCAG35B/RXM35N9 FCAG50B/RXM50N9 FCAG60B/RXM60N9
Indoor unit FCAG35BVEB FCAG50BVEB FCAG60BVEB
Outdoor unit RXM35N2V1B9 RXM50N2V1B9 RXM60N2V1B9
Cooling capacity Nom. kW 3.50 5.00 5.70
Btu/h 11,900 17,100 19,400
kcal/h 3,009 4,299 4,901
Heating capacity Nom. kW 4.20 6.00 7.00
Btu/h 14,300 20,500 23,900
kcal/h 3,611 5,159 6,019
Power input Cooling Nom. kW 0.94 1.40 1.72
Heating Nom. kW 1.11 1.62 2.07
2-3 Capacity and Power input FVXM25F/RXM25N9 FVXM35F/RXM35N9 FVXM50F/RXM50N9
