Daikin RXM25N2V1B9 [18/55] Specifications
![Daikin RXM25N2V1B9 [18/55] Specifications](/views2/1772908/page18/bg12.png)
• Outdoor Unit • RXM-N9
2
• Split - Sky Air • RXM-N9
16
2 Specifications
Notes
See separate drawing for electrical data
See separate drawing for operation range
Nominal cooling capacities are based on: indoor temperature: 27°CDB, 19°CWB, outdoor temperature: 35°CDB, equivalent refrigerant piping: 5m, level difference: 0m.
Nominal heating capacities are based on: indoor temperature: 20°CDB, outdoor temperature: 7°CDB, 6°CWB, equivalent refrigerant piping: 5m, level difference: 0m.
Power consumption in
other than active
mode
Off mode Cooling POFF kW 14.0 0.014 0.015
Heating POFF kW 14.0 0.014 0.015
Standby mode Cooling PSB kW 14.0 0.014 0.015
Heating PSB kW 14.0 0.014 0.015
Thermostat-off
mode
Cooling PTO kW 7.0 0.007
Heating PTO kW 7.0 0.007
Space heating (Warm
climate)
Energy efficiency class A+++ A++
Capacity Pdesignh kW 1.24 2.09 2.14
SCOP 5.29 5.10 4.78 4.74
SCOPnet 5.37 5.18 4.83 4.79
Annual energy consumption kWh/a 329 341 612 632
Required back up heating cap at design
conditions
kW 0.00
TOL Tol (temperature
operating limit)
°C -15
Pdh (declared
heating cap)
kW 2.03 3.68 3.93
COPd (declared COP) 2.23 2.10 1.99 2.05
Power input kW 0.91 0.97 1.85 1.92
TBivalent Tbiv (bivalent
temperature)
°C 2
Pdh (declared
heating cap)
kW 1.24 2.09 2.14
COPd (declared COP) 4.16 4.00 3.97 4.12
Power input kW 0.30 0.31 0.53 0.52
B Condition (2°C) Pdh (declared
heating cap)
kW 1.24 2.09 2.14
COPd (declared COP) 4.16 4.00 3.97 4.12
Power input kW 0.30 0.31 0.53 0.52
C Condition (7°C) Pdh (declared
heating cap)
kW 1.03 1.47 1.49
COPd (declared COP) 5.57 5.37 4.81 4.74
Power input kW 0.19 0.31
D Condition (12°C) Pdh (declared
heating cap)
kW 1.21 1.71 1.74
COPd (declared COP) 6.90 6.65 5.94 5.88
Power input kW 0.18 0.29 0.30
2-6 Capacity and Power input FBA35A9/RXM35N9 FBA50A9/RXM50N9 FBA60A9/RXM60N9
Indoor unit FBA35A2VEB9 FBA50A2VEB9 FBA60A2VEB9
Outdoor unit RXM35N2V1B9 RXM50N2V1B9 RXM60N2V1B9
Cooling capacity Nom. kW 3.40 5.00 5.70
Btu/h 11,600 17,100 19,400
kcal/h 2,923 4,299 4,901
Heating capacity Nom. kW 4.00 5.50 7.00
Btu/h 13,600 18,800 23,900
kcal/h 3,439 4,729 6,019
Power input Cooling Nom. kW 0.85 1.41 1.64
Heating Nom. kW 1.00 1.44 1.89
2-5 Capacity and Power input FFA25A9/RXM25N9 FFA35A9/RXM35N9 FFA50A9/RXM50N9 FFA60A9/RXM60N9
