• Split - Sky Air • RXM-N9
5
• Outdoor Unit • RXM-N9
2 Specifications
Notes
See separate drawing for operation range
See separate drawing for electrical data
Nominal cooling capacities are based on: indoor temperature: 27°CDB, 19°CWB, outdoor temperature: 35°CDB, equivalent refrigerant piping: 5m, level difference: 0m.
Nominal heating capacities are based on: indoor temperature: 20°CDB, outdoor temperature: 7°CDB, 6°CWB, equivalent refrigerant piping: 5m, level difference: 0m.
Power consumption in
other than active
mode
Thermostat-off
mode
PTO Cooling W 6 12
Heating W 7 13
Crankcase heater
mode
PCK W 0
Off mode POFF W 1
Standby mode Cooling PSB W 1
Heating PSB W 1
Power factor Nominal Cooling % 91.10 93.90 79.90 93.70 95.00 96.10
Heating % 97.60 98.20 90.00 95.70 96.10 99.20
Space heating (Warm
climate)
Capacity Pdesignh kW 1.24 1.29 1.35 2.15 2.48 2.58
Energy efficiency class A+++
SCOP 6.19 6.15 6.18 6.15 6.02 5.51
SCOPnet 6.31 6.26 6.30 6.27 6.13 5.59
Annual energy consumption kWh/a 280 294 305 490 576 656
Required back up heating cap at design
conditions
kW 0.00
TOL Tol (temperature
operating limit)
°C -20
Pdh (declared
heating cap)
kW 2.14 2.59 2.67 3.12
COPd (declared COP) 2.29 2.49 1.99 2.04 2.05
Power input kW 0.93 1.04 1.34 1.53 1.52
TBivalent Tbiv (bivalent
temperature)
°C 2
Pdh (declared
heating cap)
kW 1.24 1.29 1.34 3.54 2.48 2.58
COPd (declared COP) 5.10 5.13 2.72 4.67 4.31
Power input kW 0.24 0.25 0.26 1.30 0.53 0.60
B Condition (2°C) Pdh (declared
heating cap)
kW 1.24 1.29 1.34 2.15 2.48 2.58
COPd (declared COP) 5.10 5.13 4.80 4.67 4.31
Power input kW 0.24 0.25 0.26 0.45 0.53 0.60
C Condition (7°C) Pdh (declared
heating cap)
kW 0.93 0.94 0.95 1.38 1.61 1.66
COPd (declared COP) 6.28 6.22 6.30 6.47 5.64
Power input kW 0.15 0.22 0.25 0.29
D Condition (12°C) Pdh (declared
heating cap)
kW 0.97 0.98 1.09 1.54 1.80 1.95
COPd (declared COP) 7.99 7.81 7.64 7.18 6.82
Power input kW 0.12 0.14 0.20 0.25 0.29
2-2 Capacity and Power input FDXM25F9/RXM25N9 FDXM35F9/RXM35N9 FDXM50F9/RXM50N9 FDXM60F9/RXM60N9
Indoor unit FDXM25F3V1B9 FDXM35F3V1B9 FDXM50F3V1B9 FDXM60F3V1B9
Outdoor unit RXM25N2V1B9 RXM35N2V1B9 RXM50N2V1B9 RXM60N2V1B9
2-1 Capacity and Power input
FTXM20N/
RXM20N9
FTXM25N/
RXM25N9
FTXM35N/
RXM35N9
FTXM42N/
RXM42N9
FTXM50N/
RXM50N9
FTXM60N/
RXM60N9
