Vitek VT-3222N Инструкция по эксплуатации онлайн

MANUAL INSTRUCTION
ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ
STEREO RADIO CASSETTE RECORDER
ОДНОКАССЕТНАЯ МАГНИТОЛА
МОДЕЛЬ VT#3222N
Vt-3222.qxd 24.07.02 14:56 Page 2
Содержание
- Модель vt 3222n 1
- English 2
- Гарантийный талон 2
- Купон 1 2
- Купон 2 2
- Купон 3 2
- English 3
- Stereo radio cassette recorder 3
- Ac operation insert one end of the ac power cord into ac socket of the set and the other end into an ac wall outlet the batteries will be automatically disconnected 4
- Cassette operation 4
- Control operation and function 4
- Dc operation open the battery door install 6 pcs um 1 size batteries please make sure they are insert ed with correct polarity and close the door your unit is now ready for operation 4
- English 4
- Insertion and removal of cassette tape a for insertion of cassette tape depress the stop eject button to open the cassette door insert a good quality music recorded cassette tape open part of cassette facing upwards and firmly close the cassette door b for removal of cassette tape turn off the tape operation by pressing firmly stop eject button and press once again to open the cassette door then slide out the cassette tape 4
- Mic recording a install a cassette tape b place function switch to tape position c depress record button and play button simultaneously recording then starts through the built in condenser microphone d to end recording press the stop eject button or it will automatically stop when the cassette runs to the very end 4
- Playback a set function switch to tape position b insert recorded tape of your favorite music c press play button firmly down until locked and enjoy your favorite music d adjust volume and tone control to desired level e press fast fordward button firmly in case you want to forward tape f press rewind button firmly in case you want to rewind tape g when tape comes to an end in play mode tape playback will be automatically switched off 4
- Power supply this unit is designed to operate on ac mains supply or 9v dc by using 6 pieces um 1 size batteries not included 4
- Radio operation a set function switch to radio position and set band switch to your desired radio band position b tune in to your desired radio station with the tuning knob c adjust volume and tone control to desired output level d extend telescopic antenna to full extent if you are listening to fm or am broadcasting the fm stereo indicator will light when listening to a strong station that is broadcasting in stereo e turn off the radio by switching function switch to sleep position 4
- Vt 3222 qxd 24 7 2 14 56 page 8 4
- Корпус протирайте корпус магнитолы слегка влажной тканью не используйте для чистки растворители бензин абразивные средства не допускайте попадания жидкости вовнутрь прибора 4
- Русский 4
- Спецификация питание ac 220 230 в 50 гц dc 9v um 1 d x 6 частотные диапазоны fm 64 108 мгц ам 540 1600 кгц lw 150 270 кгц колонки 4 ом наушники 32 ом 4
- Срок службы магнитолы 2 года 4
- Чистка головок для обеспечения нормальной работы магнитофона регулярно чистите лентопротяжный механизм прижимной резиновый ролик магнитные головки направляющие валики и стойки чистку следует производить тампоном смоченным в спирте или специальной жидкости не используйте для чистки ворсистые ткани любые абразивные материалы и растворители загрязнение механизма зависит от качества магнитной ленты поэтому используйте только кассеты известных производителей 4
- Caution to avoid electric shock this unit must not be exposed to dripping water or water splash ventilation not being impeded 5
- English русский 5
- Headphone jack for private listening insert a 3 mm headphone not included into the headphone jack the speakers output is automatically cut off caution listening at high power for along moment could damage users ears 5
- Precautions and maintenance a avoid placing this unit near sources of high temperature such as fireplace or sunlight for long time as this may result in damages to plastic housing or electrical parts inside the unit b if you are not using the unit for an extended period of time please remove batteries as bat teries may leak and cause damages c be sure to press stop button before inserting or removing cassette tape d as playback head might get oxidized after certain time of use this can be cleaned with cot ton swab or q tip dipped in alcohol e there are no serviceable parts inside the unit therefore do not open back cover of unit in case of any defect or repair of unit please refer to qualified service center 5
- Radio recording a install a cassette tape b place function switch to radio position after selecting the desired band and tune the tuning knob to desired broadcast station then push down record button and play button simultaneously c after recording the desired broadcast depress the stop eject button lightly and then place function switch to tape position in order to listen to the recorded broadcast d if you desire to play recorded broadcast please follow the instructions explained in play back section erasure when you record over previously recorded tape the original recording is automat ically erased and replaced by this newly recording material 5
- Service life of the stereo radio cassette recorder 2 year 5
- Specifications power supply ac 220 230 v 50hz dc 9v um 1 d x 6 radio frequence coverage fm 64 108 mhz am 540 1600 khz lw 150 270 khz terminal impedans speaker 4 ohms headphone 32 ohms 5
- Кнопка пауза 2 кнопка стоп выброс кассеты 3 кнопка ускоренной перемотки вперед 4 кнопка ускоренной перемотки назад 5 кнопка воспроизведение 6 кнопка запись 7 гнездо для подключения наушников 8 функциональный переключатель 9 регулятор тембра 10 регулятор громкости 11 встроенный микрофон 6
- Русский 6
- Частотный переключатель 13 антенна 14 регулятор настройки 15 шкала настройки 16 гнездо для подключения сетевого шнура 17 отсек для кассеты 18 отсек для батареек 19 ручка магнитолы 20 динамики 21 индикатор fm стерео 6
