Si04-306 Specifications
Specifications 11
230V, 50Hz
Notes:
MAX. interunit piping length: 30m
MIN. interunit piping length: 1.5m
MAX. interunit height difference: 20m
Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m
The data are based on the conditions shown in the table below.
Model
Indoor Units FTKS50BVMB FTKS60BVMB FTKS71BVMB
Outdoor Units RKS50BVMB RKS60BVMB RKS71BVMB
Capacity
Rated (Min.~Max.)
kW 5.0 (0.9~5.8) 6.0 (0.9~6.7) 7.1 (0.9~8.0)
Btu/h 17,070 (3,070~19,800) 20,480 (3,070~22,870) 24,240 (3,070~27,310)
kcal/h 4,300 (770~4,990) 5,160 (770~5,760) 6,110 (770~6,880)
Moisture Removal L/h 2.9 3.9 4.5
Running Current (Rated) A 7.3 9.3 11.1
Power Consumption
Rated (Min.~Max.)
W 1,660 (450~2,300) 2,120 (450~2,450) 2,530 (450~3,070)
Power Factor % 98.9 99.1 99.1
COP W/W 3.01 2.83 2.81
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
12.7
φ
15.9
Drain mm
φ
18.0
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Unit FTKS50BVMB FTKS60BVMB FTKS71BVMB
Front Panel Color White White White
Air Flow Rate
m³/min
(cfm)
H 11.4 (402) 16.2 (572) 16.7 (590)
M 9.7 (342) 13.6 (480) 14.2 (501)
L 8.0 (282) 11.4 (402) 11.6 (409)
SL 7.1 (251) 10.2 (360) 10.6 (374)
Fan
Type Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor Output W 40 43 43
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removable/Washable/Mildew Proof Removable/Washable/Mildew Proof Removable/Washable/Mildew Proof
Running Current (Rated) A 0.18 0.18 0.20
Power Consumption (Rated) W 40 40 45
Power Factor % 96.6 96.6 96.4
Temperature Control Microcomputer Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×795×238 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 280×840×338 337×1,147×366 337×1,147×366
Weight kg 9 12 12
Gross Weight kg 13 17 17
Operation
Sound
H/M/L/SL dBA 44/40/35/32 45/41/36/33 46/42/37/34
Sound Power H dBA 63 63 63
Outdoor Unit RKS50BVMB RKS60BVMB RKS71BVMB
Casing Color Ivory White Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC32HXD 2YC32HXD 2YC45BXD
Motor Output W 1,500 1,500 1,900
Refrigerant Oil
Type FVC50K FVC50K FVC50K
Charge L 0.65 0.65 0.75
Refrigerant
Type R410A R410A R410A
Charge kg 1.20 1.70 1.70
Air Flow Rate m³/min (cfm)
H 47.7(1,684) 47.6 (1,680) 51.5 (1,818)
L 44.1(1,557) 44.1 (1,557) 41.5 (1,465)
Fan
Type Propeller Propeller Propeller
Motor Output W 53 53 53
Running Current (Rated) A 6.82 9.12 10.90
Power Consumption (Rated) W 1,620 2,080 2,485
Power Factor % 99.0 99.2 99.1
Starting Current A 7.3 9.3 11.1
Dimensions (H×W×D) mm 735×825×300 735×825×300 735×825×300
Packaged Dimensions (H×W×D) mm 784×960×390 784×960×390 784×960×390
Weight kg 49 52 55
Gross Weight kg 53 57 59
Operation
Sound
H dBA 47 49 52
Sound Power H dBA 63 64 66
Drawing No. 3D040781A 3D040782A 3D040783A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
