Si04-604 List of Functions
List of Functions 3
Category Functions
FTXG25/35EV1BW(S)
RXG25/35E2V1B
ATXG25/35EV1B
ARXG25/35E2V1B
Category Functions
FTXG25/35EV1BW(S)
RXG25/35E2V1B
ATXG25/35EV1B
ARXG25/35E2V1B
Basic
Function
Inverter (with Inverter Power Control) {{
Health &
Clean
Air Purifying Filter with Bacteriostatic,
Virustatic Functions
——
Operation Limit for Cooling (°CDB)
10
~46
10
~46
Operation Limit for Heating (°CWB)
–15
~20
–15
~20
Photocatalytic Deodorizing Filter — —
PAM Control {{
Air Purifying Filter with Photocatalytic
Deodorizing Function
——
Compressor
Oval Scroll Compressor — —
Titanium Apatite Photocatalytic
Air-Purifying Filter
{{
Swing Compressor {{
Rotary Compressor — — Mold Proof Air Filter {{
Reluctance DC Motor {{ Wipe-clean Flat Panel {{
Comfortable
Airflow
Power-Airflow Flap {{ Washable Grille — —
Power-Airflow Dual Flaps — — Mold Proof Operation — —
Power-Airflow Diffuser — — Heating Dry Operation — —
Wide-Angle Louvers {{ Filter Cleaning Indicator — —
Vertical Auto-Swing (Up and Down) {{ Good-Sleep Cooling Operation — —
Horizontal Auto-Swing (Right and Left)
{{
Timer
24-Hour On/Off Timer
{{
3-D Airflow
{{
Night Set Mode
{{
Comfort Airflow Mode {{
Worry Free
“Reliability &
Durability”
Auto-Restart (after Power Failure) {{
3-Step Airflow (H/P Only) — — Self-Diagnosis (Digital, LED) Display {{
Comfort
Control
Auto Fan Speed {{ Wiring Error Check — —
Indoor Unit Silent Operation {{
Anticorrosion Treatment of Outdoor
Heat Exchanger
{{
Night Quiet Mode (Automatic) — —
Outdoor Unit Silent Operation (Manual) {{
Flexibility
Multi-Split / Split Type Compatible
Indoor Unit
{{
Intelligent Eye {{
Quick Warming Function
{{
Flexible Voltage Correspondence — —
Hot-Start Function
{{
High Ceiling Application — —
Automatic Defrosting
{{
Chargeless 10m 10m
Operation
Automatic Operation
{{
Either Side Drain (Right or Left)
{{
Programme Dry Function
{{
Power Selection — —
Fan Only {{
Remote
Control
5-Rooms Centralized Controller
(Option)
{{
Lifestyle
Convenience
New Powerful Operation (Non-Inverter) — —
Remote Control Adaptor
(Normal Open-Pulse Contact) (Option)
{{
Inverter Powerful Operation {{
Priority-Room Setting — —
Remote Control Adaptor
(Normal Open Contact) (Option)
{{
Cooling / Heating Mode Lock — —
Home Leave Operation — — DIII-NET Compatible (Adaptor) (Option)
{{
ECONO Mode — —
Remote
Controller
Wireless
{{
Indoor Unit On/Off Switch
{{
Wired — —
Signal Reception Indicator
{{
Temperature Display — —
Another Room Operation — —
Note:
{
: Holding Functions
— : No Functions
