• Outdoor Units • R-410A • RKH-CAVMB
1
2
• Split Sky Air • Outdoor Units3
2 Specifications
Piping
connections
Liquid (OD) Diameter
(OD)
mm 6.35 6.35 6.35
Gas Diameter
(OD)
mm 9.5 9.5 9.5
Drain Diameter
(OD)
mm 18 18 18
Piping Length Maximum m 15 15 15
Additional Refrigerant
Char ge
kg/m 0 .02 />10 m
Max. internunit level
difference
m 10.0 10.0 10.0
Heat Insulation Both liquid and gas pipes
Standard
Accessories
Item Installation manual
Quantity 1 1 1
Notes Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,
equivalent refrigerant piping : 7.5m, level difference : 0m.
Sound levels are measured in an anechoic room
Sound pressure level is a relative value, depending on the distance and acoustic environment. For more details,
please refer to sound level drawings of this chapter.
The sound power level is an absolute value indicating the power which a sound source generates.
2-3 ELECTRICAL SPECIFICATIONS RKH20CAVMB RKH25CAVMB RKH35CAVMB
Power Supply Name VM
Phase 111
Frequency Hz 50/60
Voltage V 220-240/220-230
Voltage range Minimum V -10%
Maximum V +10%
Current Nominal
running current
(RLA)
Cooling A 3.12 3.52 4.72
Starting current (cooling/
heating)
A 3.3 3.7 4.9
Wiring
connections
For Power
Supply
Quantity 3 3 3
For connection
with indoor
Quantity 4 4 4
Remark included earth wiring
Power Supply Intake Outdoor unit only
2-2 TECHNICAL SPECIFICATIONS RKH20CAVMB RKH25CAVMB RKH35CAVMB
