Daikin RKH20CAVMB [8/33] Capacity tables

• Split Sky Air • Outdoor Units 8

• Outdoor Units • R-410A • RKH-CAVMB

5 Capacity tables

5 - 1 Cooling capacity tables

FTKS35C+ RKH35C

Cooling capacity 230V [50Hz]

AFR 7.7

BF 0.18

Indoor Outdoor temperature (°C)

EWB EDB 20 25 30 32 35 40

(°C) (°C) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI

14.0 20 2.93 2.14 0.78 2.84 2.07 0.87 2.74 2.00 0.96 2.69 1.97 0.98 2.62 1.92 1.00 2.51 1.84 1.08

16.0 22 3.17 2.31 0.80 3.06 2.24 0.89 2.96 2.16 0.98 2.91 2.12 1.00 2.83 2.07 1.02 2.72 1.98 1.10

18.0 25 3.40 2.49 0.81 3.29 2.40 0.90 3.18 2.32 1.00 3.13 2.28 1.01 3.04 2.22 1.04 2.92 2.13 1.12

19.0 27 3.52 2.57 0.82 3.41 2.49 0.91 3.29 2.40 1.01 3.23 2.36 1.02 3.15 2.30 1.05 3.02 2.20 1.13

22.0 30 3.89 2.84 0.84 3.76 2.75 0.94 3.63 2.65 1.04 3.57 2.61 1.05 3.48 2.54 1.08 3.33 2.43 1.16

24.0 32 4.14 3.02 0.86 4.00 2.92 0.96 3.86 2.82 1.06 3.80 2.77 1.07 3.70 2.70 1.10 3.55 2.59 1.19

3D044313

SYMBOLS

AFR: Air flow rate (m

/min)

BF: Bypass factor

EWB: Entering wet bulb temp. (°CWB)

EDB: Entering dry bulb temp. (°CDB)

TC: Total capacity (kW)

SHC: Sensible heating capacity (kW)

PI: Power input (kW)

NOTES

1. Ratings shown are net capacities which include a deduction for indoor fan

motor heat

2. Shows nominal cooling capacities and power input

3. TC, PI and SHC must be calculated by interpolation using the figures in the

above tables. (Figures out of the tables should not be used for calculation.)

4. SHC is based on each EWB and EDB

SHC* = SHC correction for other dry bulb

SHC*=0.02xAFR(m

/min)x(1-BF)x(DB-EDB)

Add SHC* to SHC.

5. Capacities are based on following conditions:

Corresponding refrigerant piping length: 5 m

Level difference: 0 m

6. Air flow rate (AFR) and Bypass factor (BF) are taburated above.
