SiBE12-933_A Printed Circuit Board Connector Wiring Diagram
Printed Circuit Board Connector Wiring Diagram 41
1.1.3 FTXG25/35E, CTXG50E, ATXG25-50E
Connectors PCB (1) (Control PCB)
PCB (2) (Signal Receiver PCB)
PCB (3) (INTELLIGENT EYE sensor PCB)
Note: Other designations
PCB (1) (Control PCB)
PCB (2) (Signal Receiver PCB)
1) S1 Connector for fan motor
2) S21 Connector for centralized control (HA)
3) S32 Connector for heat exchanger thermistor
4) S36 Connector for INTELLIGENT EYE sensor PCB
5) S41 Connector for swing motor
6) S46 Connector for signal receiver PCB
7) S49 Connector for reduction motor (front panel mechanism)
8) S51 Connector for front panel limit switch
1) S47 Connector for control PCB
1) S36 Connector for control PCB
1) V1 Varistor
2) JA Address setting jumper
JB Fan speed setting when compressor is OFF on thermostat
JC Power failure recovery function (auto-restart)
∗
Refer to page 255 for detail.
3) FU1 (F1U) Fuse (3.15A)
4) LED A LED for service monitor (green)
1) SW1 (S1W) Forced cooling operation ON / OFF switch
2) LED2 LED for INTELLIGENT EYE (green)
3) LED3 LED for timer (yellow)
4) LED4 LED for operation (green)
5) RTH1 (R2T) Room temperature thermistor
