- 19 -
• FIXING THE HOOD TO THE LOWER PART OF THE
WALL CABINET
This type of appliance must be fitted inside a cabinet or
inside another type of support structure. To fix it in place,
use 4 screws which are suitable for the type of cabinet,
making holes in accordance with the diagram shown in
(fig. 1). To fit the appliance correctly, align the front panel
of the cooker hood with the cabinet door and adjust
spacer E using screws P (fig. 2), then ensure the
appliance meets the cabinet at the rear.
• EXTRACTION THROUGH AN OUTSIDE WALL
The appliance expels the fumes through an outside wall
or a duct. It is necessary to buy a telescopic pipe in
accordance with the standards in use (inflammable) and
connect it to flange B (Fig 3).
Remove the charcoal filters already fitted to the appliance
by turning them 90° anticlockwise (Fig. 7).
• RECIRCULATION
The clean air is returned into the room through a
connecting tube passing inside the cupboard and
connected to the ring B (fig 4).
The charcoal filters are already fitted to the appliance.
USE AND MAINTENANCE
• We recommend that the cooker hood is switched on
before any food is cooked. We also recommend that the
appliance is left running for 15 minutes after the food is
cooked, in order to thoroughly eliminate all contaminated
air.
The effective performance of the cooker hood depends
on constant maintenance; the anti-grease filter and the
active carbon filter both require special attention.
• The anti-grease filter is used to trap any grease particles
suspended in the air, therefore is subject to saturation
(the time it takes for the filter to become saturated
depends on the way in which the appliance is used).
The acrylic filter, which is found resting on the grille,
should be replaced when the text, visible through the
grille, changes colour and the ink spreads; the new filter
should be fitted in such a way that the text can be seen
through the grille from outside the cooker hood.
If the filters do not have any text on them, or if metal
filters or aluminium panel filters are used, they should
be washed every 2 months in order to prevent the risk of
fire. To wash the filters, proceed as follows:
- Remove the filter from the grille and wash it using a
solution of water and neutral liquid detergent, leaving
the dirt to soften.
- Rinse thoroughly with warm water and leave to dry.
The metal filters and/or aluminium panel are also
dishwasher safe. If the filters are made using aluminium,
or if an aluminium panel is used, after a few washes the
colour may change. This does not mean they have to be
replaced.
If the replacement and washing instructions are not
followed, the anti-grease filters may present a fire hazard.
• The active carbon filters are used to purify the air which
is released back into the room. The filters are not
washable or re-usable and must be replaced at least once
every four months. The active carbon filter saturation level
depends on the frequency with which the appliance is
used, the type of cooking performed and the regularity
with which the anti-grease filters are cleaned.
• Remove build-up from the fan and other surfaces of
the cooker hood regularly using a cloth moistened with
denatured alcohol or non-abrasive neutral liquid
detergent.
• The light on the cooker hood is designed for use during
cooking and not for general room illumination. Extended
use of the light reduces the average duration of the bulb.
• COMANDI: (Fig.8) SLIDER the key symbols are
explained below:
This hood is fitted with a
microswitch which allows the
activation of the motor speed) through the opening of the
telescopic undercarriage. If the telescopic undercarriage
is closed the motor speeds cannot be activated.
This microswitch does not have an impact on the
activation of the lights which must be switched on through
the appropriate switch (see fig.8A).
A = Light switch
A1 = Off key
A2 = On key
B = Speed control
B1 = FIRST SPEED key
B2 = SECOND SPEED key
B3 = THIRD SPEED ke
Warning! If the telescopic undercarriage is closed with
the speed set at 2,, once it is re-opened, the hood will
be reactivated with the same speed in use when the hood
was closed.
• Replacing incandescent light bulbs (Fig. 1A).
To remove the incandescent light bulb, take out the
grease filters as described in (Fig. 6) and remove the
bulb.
Replace it with a new one of the same type (Fig. 1A).
CUSTOMER ASSISTANCE SERVICE
Before contacting the Technical Assistance Service:
If the product does not operate at all, we advise you to:
- check that the plug has been inserted into the power
socket correctly.
If you cannot identify the cause of the operating anomaly:
switch off the appliance (do not subject it to rough
treatment) and contact the Assistance Service.
PRODUCT SERIAL NUMBER. Where can I find it?
It is important that you inform the Assistance Service of
your product code and its serial number (a 16-character
code which begins with the number 3); this can be found
on the guarantee certificate or on the data plate located
inside the appliance.
This will help to avoid wasted journeys being made by
technicians, thereby (and most significantly) saving the
corresponding callout charges.
THE MANUFACTURER DECLINES ALL
RESPONSIBILITY FOR EVENTUAL DAMAGES
CAUSED BY BREACHING THE ABOVE WARNINGS.
