SiBE12-712 Troubleshooting
Service Diagnosis 199
4. Troubleshooting
4.1 Error Codes and Description
: Displayed only when system-down occurs.
Code Indication Description
Reference
Page
System
00
Normal —
U0
Insufficient gas 230
U2
Over-voltage detection / low-voltage detection 232
U4
Outdoor unit PCB abnormality or signal transmission circuit abnormality 234
UA
Unspecified voltage (between indoor and outdoor units) 233
UH
Anti-icing function in other rooms 233
Indoor
Unit
A1
Indoor unit PCB abnormality 200
A5
Freeze-up protection control or high pressure control 201
A6
Fan motor or related
abnormality
AC motor (Wall : FTK(X)S-C, ATK(X)S-D series, Duct, Floor /
Ceiling)
203
DC motor (Wall : FTK(X)S-D, ATK(X)S-E series, FTXG-E,
ATXG-E series, Floor)
204
C4
Heat exchanger temperature thermistor abnormality 206
C7
Front Panel Open / Close Fault 207
C9
Room temperature thermistor abnormality 206
Outdoor
Unit
A5
Anti-icing function 208
E5
OL activation (compressor overload) 210
E6
Compressor lock 211
E7
DC fan lock 212
E8
Input over current detection 213
F3
Discharge pipe temperature control 215
F6
High pressure control in cooling 216
H0
Compressor sensor system abnormality 218
H6
Position sensor abnormality 218
H8
DC voltage / DC current sensor abnormality 221
H9
Outdoor air thermistor or related abnormality 222
J3
Discharge pipe temperature thermistor or related abnormality 222
J6
Heat exchanger temperature thermistor or related abnormality 222
J8
Liquid pipe temperature thermistor or related abnormality 222
J9
Gas pipe temperature thermistor or related abnormality 222
L3
Electrical box temperature rise 224
L4
Radiation fin temperature rise 226
L5
Output over current detection 228
P4
Radiation fin thermistor or related abnormality 222
