Heat Pump SiBE12-712
30 Specifications
50Hz 230V
Model
ATXG25EV1B ATXG35EV1B
Cooling Heating Cooling Heating
Rated Capacity 2.5kW Class 3.5kW Class
Front Panel Color Mat Crystal White Mat Crystal White
Air Flow Rates
m³/min
(cfm)
H 7.7 (271) 9.0 (317) 8.1 (285) 9.6 (338)
M 6.1 (215) 7.9 (278) 6.5 (229) 8.2 (289)
L 4.7 (165) 6.7 (236) 4.9 (173) 6.7 (236)
SL 3.8 (134) 5.4 (190) 4.1 (144) 5.9 (208)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.14 0.14 0.14 0.14
Power Consumption (Rated) W 30 30 30 30
Power Factor % 93.2 93.2 93.2 93.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 275×840×150 275×840×150
Packaged Dimensions (H×W×D) mm 222×894×345 222×894×345
Weight kg 9 9
Gross Weight kg 13 13
Operation
Sound
H/M/L/SL dBA 38/32/25/22 38/33/28/25 39/33/26/23 39/34/29/26
Sound Power H dBA 56 56 57 57
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D051107 3D051108
Model
ATXS20E2V1B ATXS25E2V1B
Cooling Heating Cooling Heating
Rated Capacity 2.0kW Class 2.5kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 8.7 (307) 9.4 (332) 8.7 (307) 9.4 (332)
M 6.7 (237) 7.6 (268) 6.7 (237) 7.6 (268)
L 4.7 (166) 5.8 (205) 4.7 (166) 5.8 (205)
SL 3.9 (138) 5.0 (177) 3.9 (138) 5.0 (177)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.16 0.16 0.16 0.16
Power Consumption (Rated) W 35 35 35 35
Power Factor % 95.1 95.1 95.1 95.1
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 283×800×195 283×800×195
Packaged Dimensions (H×W×D) mm 265×855×340 265×855×340
Weight kg 9 9
Gross Weight kg 12 12
Operation
Sound
H/M/L/SL dBA 38/32/25/22 38/33/28/25 38/32/25/22 38/33/28/25
Sound Power H dBA 56 56 56 56
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D051746 3D051747
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
