Daikin RKS60F2V1B [4/31] Specifications
![Daikin RKS35F2V1B [4/31] Specifications](/views2/1776840/page4/bg4.png)
3
1
2
• Split Sky Air • Outdoor Units
4
• Outdoor Units • R-410A • RKS-F2V1B
2 Specifications
2-2 TECHNICAL SPECIFICATIONS
RKS25F2V1B RKS35F2V1B RKS50F2V1B RKS60F2V1B RKS71FV1B
Casing Colour Ivory White
Dimensions Unit Height mm 600 550 735 735 770
Width mm 700 765 825 825 900
Depth mm 210 285 300 300 320
Packing Height mm 696 617 797 797 900
Width mm 786 882 960 960 925
Depth mm 286 363 390 390 390
Weight Unit kg 14 34 48 47 71
Packed Unit kg 18 40 52 52 78
Heat
Exchanger
Dimensions Length mm 805 805 845 845 859
Nr of Rows 2 2 2 2 2
Fin Pitch mm 1.4 1.4 1.8 1.8 1.4
Nr of Stages 24 24 32 32 34
Tube type Hi-Xa(7) Hi-Xa(7) Hi-Xa(8) Hi-Xa(8) Hi-Xa(7)
Fin Type Waffle fin
Treatment Anti-corrosion treatment (PE)
Fan Type Propeller Turbo fan Propeller Propeller Propeller
Quantity 1 1 1 1 1
Air Flow Rate
(nominal at
230V)
Cooling m³/min 33.5 33.5 48.9 50.9 54.5
Motor Quantity 1 1 1 1 1
Model D23B-28 D23B-28 KFD-380-50-8A KFD-380-50-8A KFD-280-66-8A
Motor Speed
(nominal)
Cooling rpm 860(H) - 620(L) 860(H) - 620(L) 780 810 860
Fan Motor Output W 23 23 53 66
Compressor Quantity 1 1 1 1 1
Motor Model 1YC23NXD#C 1YC23NXD#C 2YC36BXD#C 2YC36BXD#C 2YC63BXD#D
Type Hermetically sealed swing compressor
Motor
Output
W 600 1100 1100 1920
Operation
Range
Cooling Min °CDB -10 -10 -10 -10 -10
Max °CDB 46 +46 46 46 46
Sound Level
(nominal)
Cooling Sound
Power
dBA 61 62 61 63 66
Sound
Pressure
dBA 46(H) - 43(L) 47(H) - 44(L) 47(H)/44(L) 49(H) - 46(SL) 52
Sound Level
(Night quiet)
Sound Pressure dBA 49
Refrigerant Type R-410A
Charge kg 1.0 1.0 1.5 1.5 2.3
Refrigerant Oil Type FVC50K
Charged Volume l 0.375 0.375 0.65 0.65 0.75
Piping
connections
Liquid (OD) Quantity 1 1 1
Diameter
(OD)
mm 6.35 6.35 6.35 6.35 6.35
Gas Quantity 1 1 1
Diameter
(OD)
mm 9.5 9.5 12.7 12.7 15.9
Drain Quantity 1 1 1
Diameter
(OD)
mm 20 20 20 18 18
Piping Length Maximum m 20 20 30 30 30
Chargele
ss
m 10 10 10 10 10
Additional Refrigerant
Charge
kg/m 0.02/>10m 0.02/10m 0.02/>10 0.02/>10m 0.02/>10m
Installation
height
difference
Maximum m 15 15 20 20 20
Heat Insulation Both liquid and gas pipes
