Functions SiBE07-618_D
4 List of Functions
Category Functions
FDKS50/60CVMB
RKS50G2V1B, RKS60F3V1B
FDXS50/60CVMB
RXS50G2V1B, RXS60F3V1B
Category Functions
FDKS50/60CVMB
RKS50G2V1B, RKS60F3V1B
FDXS50/60CVMB
RXS50G2V1B, RXS60F3V1B
Basic
Function
Inverter (with Inverter Power Control)
{{
Health &
Clean
Air-Purifying Filter — —
Operation Limit for Cooling (°CDB)
–10
~46
★
–
10
~46
Photocatalytic Deodorizing Filter — —
Operation Limit for Heating (°CWB) —
–15
~18
Air-Purifying Filter with Photocatalytic
Deodorizing Function
——
PAM Control
{{
Titanium Apatite Photocatalytic
Air-Purifying Filter
——
Compressor Oval Scroll Compressor — —
Swing Compressor
{{
Air Filter (Prefilter)
{{
Rotary Compressor — — Wipe-Clean Flat Panel — —
Reluctance DC Motor
{{
Washable Grille — —
Comfortable
Airflow
Power-Airflow Flap — — Mold Proof Operation — —
Power-Airflow Dual Flaps — — Heating Dry Operation — —
Power-Airflow Diffuser — — Good-Sleep Cooling Operation — —
Wide-Angle Louvers — — Timer 24-Hour ON/OFF TIMER
{{
Vertical Auto-Swing (Up and Down) — — NIGHT SET Mode
{{
Horizontal Auto-Swing (Right and Left) — — Worry Free
“Reliability &
Durability”
Auto-Restart (after Power Failure)
{{
3-D Airflow — — Self-Diagnosis (Digital, LED) Display
{{
Comfort
Control
Auto Fan Speed
{{
Wiring Error Check — —
Indoor Unit Quiet Operation
{{
Anti-Corrosion Treatment of Outdoor
Heat Exchanger
{{
NIGHT QUIET Mode (Automatic) — —
OUTDOOR UNIT QUIET Operation
(Manual)
{{
Flexibility Multi-Split / Split Type Compatible
Indoor Unit
{{
INTELLIGENT EYE Operation — — Flexible Voltage Correspondence — —
Quick Warming Function
(Preheating Operation)
—
{
High Ceiling Application — —
Chargeless 10 m 10 m
Hot-Start Function —
{
Either Side Drain (Right or Left) — —
Automatic Defrosting —
{
Power Selection — —
Operation Automatic Operation —
{
Remote
Control
5-Rooms Centralized Controller
(Option)
{{
Program Dry Operation
{{
Fan Only
{{
Remote Control Adaptor
(Normal Open Pulse Contact) (Option)
{{
Lifestyle
Convenience
New POWERFUL Operation
(Non-Inverter)
——
Inverter POWERFUL Operation
{{
Remote Control Adaptor
(Normal Open Contact) (Option)
{{
Priority-Room Setting — —
COOL / HEAT Mode Lock — — DIII-NET Compatible (Adaptor) (Option)
{{
HOME LEAVE Operation
{{
Remote
Controller
Wireless
{{
ECONO Operation — — Wired (Option)
{{
Indoor Unit ON/OFF Button
{{
Signal Receiving Sign
{{
Temperature Display — —
Note:
{
: Holding Functions
— : No Functions
★
: Lower limit can be extended to –15°C by turning
switch. (facility use only)
