ED04-805 Features
Room Air Conditioners E-Series 9
05RAG19A- 32
Wipe-clean Flat Panel
Grille Type :
Remove and wash the grille
Current models are …
New Flat Panel : Easy to clean without removing the panel
New models are …
Also washable after
removing the panel.
