Cooling Only Si12-710
10 Specifications
1.2 Outdoor Units
50Hz 230V
Note:
1. The data are based on the conditions shown in the table below.
Model 2MKS40FV1B
Cooling Capacity kW —
Power Consumption W —
Running Current A —
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 1YC23ABXD
Motor Output W 600
Refrigerant
Oil
Model FVC50K
Charge L 0.45
Refrigerant
Type R-410A
Charge kg 1.20
Air Flow Rate
m³/min
HH 36
H33
L30
cfm
HH 1,271
H 1,165
L 1,059
Fan
Type Propeller
Motor Output W 50
Starting Current A 5.9
Dimension (H
×
W
×
D) mm 550
×
765
×
285
Packaged Dimension (H
×
W
×
D) mm 612
×
906
×
362
Weight kg 38
Gross Weight kg 43
Operation
Sound
(Sound pressure) dBA 47
(Quiet Mode) dBA 43
Sound Power dBA 62
Piping
Connection
Liquid mm
φ
6.4
×
2
Gas mm
φ
9.5
×
2
Drain mm
φ
18
Heat Insulation Both Liquid & Gas Pipes
No. of Wiring Connection 3 for Power Supply, 4 for Interunit Wiring
Max. Piping Length m
30 (for Total of Each Room)
20 (for One Room)
Min. Piping Length m 3 (for One Room)
Amount of Additional Charge g/m 20 (20m or more)
Max. Installation Height Difference m
15 (between Indoor Unit and Outdoor Unit)
7.5 (between Indoor Units)
Drawing No. 3D055840
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB
5m
