Ghibli Round 45 E 55 TOUCH [10/18] Filling the tank
![Ghibli Round 45 E 55 TOUCH [10/18] Filling the tank](/views2/1777795/page10/bga.png)
EN
EN-7
6.1 FILLING THE TANK
(Fig. 7)
WARNING:
Only add clean mains water to the tank at
a temperature no greater than 50°C.
- Remove the hose (26) supplied, connect
one end (26a) to a tap and insert the oth-
er end (26b) in the tank (5).
- Check that the tap (40) is open.
- Turn on the tap and fill the tank (5) to the
MAXIMUM LEVEL (NOT EXCEED) indi-
cated by the label placed on the transpar-
ent tube (15).
- Pour the liquid detergent into the tank for
machines not equipped with chemical kit.
N.B.:
Use non-foamy detergents only. For the
quantities, follow the instructions provided by
the detergent manufacturer according to the
type of dirt.
DANGER:
If the detergent comes in contact with the
eyes and/or skin or if swallowed, refer to
the use and safety information booklet
provided by the manufacturer of the de-
tergent.
7.1 OPERATION (Fig. 8)
7.1.a - Checks before use
- Check that the exhaust tube (12) of the
recovery tank is properly coupled and
properly sealed.
- Check that the connector (41) on the
squeegee (11) is not blocked and that the
hose is connected correctly.
- Check that the clean water exhaust tube
(15) is correctly coupled to the supports
and that the tap (40) is open.
Working cycle:
- The machine can perform 4 working cy-
cles:
Drying only cycle:
- In order to perform the drying cycle alone,
press the switch (35). The suction unit will
activate.
Brushing only cycle:
- To perform only the brushing cycle, press
the switch (38) to enable brush rotation.
Touch the touch sensor to start the rota-
tion of the brush.
Washing, brushing cycle:
- Press the switch (38) to enable brush
rotation, press the switch (39) to enable
water dispensing.
Touch the touch sensor to start the rota-
tion of the brush and the water supply.
Washing, brushing, drying cycle:
- Press the switch (35) to start the aspira-
tor, switch (38) to enable brush rotation
and press the switch (39) to enable water
dispensing.
Touch the touch sensor to start the rota-
tion of the brush and the water supply.
7.1.d - Using the machine (Fig. 1)
- After turning the machine on and se-
lecting the cycle, the cleaning operation
starts, pushing the machine with the help
of the handle (1).
N.B.:
Pay attention to particularly delicate floors;
do not use the machine while it’s stopped
and the brush rotation on.
N.B.:
The proper cleaning and drying of the oor
is done by pushing the machine forwards;
if you go backwards the machine will not
perform drying; in this phase, always lift the
wiper to avoid damaging the blades.
7.1.b - Electrical connection
- Introduce the cable (42) of an extension
in the tear-proff hook (28) locking it as
shown in figure.
- Connect the outlet (43) of the extension
cord (42) with the plug (16) of the ma-
chine.
- Connect the power cord to an outlet hav-
ing minimum capacity of 10A.
WARNING:
- Make sure that the mains system is
equipped with an RCD (circuit breaker).
- Unwind the electric power cable com-
pletely before operating the appliance.
- Use an electrical extension lead only
if in perfect condition; ensure that the
section is appropriate for the appliance
power rating.
- Never let the power cable run over
sharp edges and do not tread on it.
7.1.c - Preparing the machine and
choosing the cycle (Figg. 6-9)
- Press the switch (34 Fig. 6).
- Release the lever (3 Fig. 9) and lower it;
theoorsqueegee(11Fig.9)islowered.
- Press down on the pedal (19 Fig. 9), re-
lease it from its coupling and lift it, the
brush (10 Fig. 1) will be lowered.
NOTE:
The brush has two working positions;
Normal position “A”
It is automatically placed when you release
the pedal (19 Fig. 9) from the lifted position.
Position for persistent dirt “B”
From the “A” working position, lift the pedal
(19 Fig. 9) and engage it in the “B1” holder;
an additional pressure of 5 kg will be exer-
cised on the brush.
