Ghibli Round 45 E 55 TOUCH [12/18] Fig 12

EN-9

- Remove the cap (46) from the hose (12)

and drain all the water contained in the

tank.

N.B.:

The amount of water that comes out can be

modulated by pressing on the end of the tube

(12).

- Screw the cap (46) back on the tube (12)

and put it back on its support.

9.1 MAINTENANCE AND

CLEANING

WARNING:

All maintenance operations must be per-

formed with the machine off and tanks

empty.

OPERATIONS TO

PERFORM DAILY

9.1.a - Emptying and cleaning the

clean water tank (Fig. 13)

WARNING:

At the end of the washing operations, it is

compulsory to drain and clean the clean

water tank (5) to prevent deposits or scal-

ing.

After draining the recovery water tank, drain

the clean water tank as follows:

- Position the machine over a drain outlet.

- Disconnect the tube (15) from the hooks,

close the tap (40), lower the tube to the

ground on the drain outlet, open the tap

(40) and let the water drain completely.

- Wash the inside of the tank, leaving the

drain hose open and adding clean water

through the top opening.

- When cleaning is complete, lift the tube

(15), leaving the tap (40) open; couple

the tube in its recesses.

WARNING:

Always lift the wiper and the end piece

after finishing the cleaning operations be-

cause this avoids the deformation of the

rubber blades and of the brush hairs.

- Press the switch (34 Fig. 6) on “0” to turn

off the machine.

- Disconnect the plug from the socket.

7.1.h - Maximum recovery tank water

level alarm

If during use of the machine, the vacuum

cleaner turns off, it means that the level of

liquid in the recovery tank has reached the

maximum level.

Go to the water drainage station and drain

the recovery tank as shown in the relative

paragraph.

NOTE:

For the proper operation of the level sensors

it is required to properly clean the inside of

the tank (14 Fig. 14).

8.1 DRAINING THE

RECOVERY WATER

(Fig. 12)

At the end of the washing cycle or when the

recovery water tank (14) is full, it is neces-

sary to empty the tank by proceeding as fol-

lows:

N.B.:

To dispose of the recovery water, comply

with the standards in force in the country in

which the machine is used.

- Position the machine near to a drain out-

let.

- Disconnect the hose (12) from the sup-

port.

- To completely drain the water from the

tank (5) disconnect the tube (47) from the

quick connector (48) then turn the con-

nector downwards, letting the water drain

completely; or remove the filter cover

(49).

9.1.b - Cleaning the recovery water

tank (Fig. 14)

WARNING:

At the end of the washing operations, it

is compulsory to clean the recovery wa-

ter tank to prevent deposits or scaling

and the proliferation of bacteria, odours

or mould.

- Drain the recovery water as shown in the

relative paragraph, positioning the ma-

chine over a drain outlet.

- Remove the cover (6).

- Leaving the hose (12) lowered and the

cap off, pour water into the tank (14)

through a hose, cleaning it until clean wa-

ter comes out of the drain hose.

- Replace all the components in reverse

order.

9.1.c - Cleaning the squeegee

(Fig. 4)

In order to clean the squeegee correctly (11),

it is necessary to remove it as follows:

- Disconnect the hose (13) from the squee-

gee (11).

- Loosen the knobs (31) and remove the

squeegee (11).

- Wash the squeegee and in particular the

rubber blades (50) and the inside of the

aspiration connector (32).

N.B.:

If, during washing, it is clear that the rubber

blades (50) are damaged or worn, it is neces-

sary to replace them or turn them over.

- Replace all the components in reverse

order.

Ghibli Round 45 E 55 TOUCH [12/18] Fig 12
