Ghibli Round 45 E 55 TOUCH [5/18] Technical data index
![Ghibli Round 45 E 55 TOUCH [5/18] Technical data index](/views2/1777795/page5/bg5.png)
EN
EN-2
Technical data
Index
* The washing width is intended with the machine operating and the brush pressed down.
Type of use Operator on ground
Characteristics
Power supply voltage See technical data plate
Installed load 1360 W
Forward movement Manual
Washing width * 530 mm
Drying width 750 mm
Theoretical hourly efficiency 2120 m
2
/h
Brushes / Pad
Diameter / Number 530 mm / 21”x1
Motor power / number 750 Wx1
Motor speed 170
rpm
Specific pressure 18,8 ÷ 22 gr/cm
2
Carter weight 29 ÷ 34 Kg
Aspiration
Motor power 600 W
Negative pressure 1791 mmH
2
O
Air flow rate 30 l / sec
Noise level 63 dB
Tank
Recirculation No
Solution capacity 45 l
Recovery capacity 47 l
Dimensions (lxwxh) without
wiper
1210 x 560 x 1040 mm
Vibrations ISO 5349 m/sec
2
< 2,5
Weight
Empty weight 91,5 Kg
Weight in running order GVW 136,5 Kg
Technical data....................................................................................................EN-3
1.1 Introduction ................................................................................................ EN-5
2.1 Getting to know the machine ....................................................................EN-5
3.1 Unpacking ...................................................................................................EN-5
3.1.a - Standard machine equipment ..........................................................EN-5
4.1 Assembling the components ....................................................................EN-5
4.1.a - Wiper assembly ................................................................................EN-5
4.1.b - Brush assembly ................................................................................EN-5
5.1 Control panel ..............................................................................................EN-6
6.1 Filling the tank ............................................................................................EN-6
7.1 Operation ................................................................................................... EN-7
7.1.a - Checks before use ............................................................................EN-7
7.1.b - Electrical connection ........................................................................EN-7
7.1.c - Preparing the machine and choosing the cycle ................................EN-7
7.1.d - Using the machine ............................................................................ EN-8
7.1.e - Adjusting the movement direction .....................................................EN-8
7.1.f - Adjusting traction help.......................................................................EN-8
7.1.g - End of use and switching off .............................................................EN-8
7.1.h - Maximum recovery tank water level alarm .......................................EN-9
8.1 Draining the recovery water .....................................................................EN-9
9.1 Maintenance and cleaning .......................................................................EN-9
9.1.a - Emptying and cleaning the clean water tank ....................................EN-9
9.1.b - Cleaning the recovery water tank ...................................................EN-10
9.1.c - Cleaning the squeegee ................................................................... EN-10
9.1.d - Cleaning the clean water filter .......................................................EN-10
9.1.e - Replacing the brush ........................................................................EN-10
9.1.f - Replacing the squeegee rubber blades ........................................... EN-11
9.1.g - Cleaning the recovery water tank ................................................... EN-11
9.1.h - Cleaning the suction filter ............................................................... EN-11
9.1.i - Replacing the fuses ......................................................................... EN-11
9.1.l - Wiper adjustment ............................................................................. EN-11
Troubleshooting ..............................................................................................EN-12
10.1 Warranty ...................................................................................................EN-13
Wiring diagram ................................................................................................EN-14
