Si04-703A Outdoor Unit
Removal Procedure 185
3
Remove the right side
panel.
4. Removing the front panel
(2)
1
Remove the 2 screws.
Step Procedure Points
(R6983)
Front Panel (1)
Front Panel (2)
(R6984)
