Daikin CDXS25CVMB [4/23] Features
![Daikin CDXS25CVMB [4/23] Features](/views2/1778561/page4/bg4.png)
1
Features
+ Slim design for flexible installation
+ Compact dimensions: can easily be mounted in a ceiling void of
only 240 mm
+ Blends unobtrusively with any interior décor
+ Can be installed in both new and existing buildings
+ Leaves maximum floor and wall space for furniture, decoration
and fittings
+ Powerful mode can be selected for rapid cooling or heating
+ The home leave operation saves energy during absence
+ Standard suction filter: removes airborne dust particles to
ensure a steady supply of clean air
+ Indoor/Outdoor unit silent operation: silent buttons on the
remote control lower the operating sound of the indoor and/or
outdoor unit by 3dB(A) each
+ Night quiet mode automatically reduces the operating sound of
the outdoor unit by 3dB(A) at night (only multi outdoor units in
cooling mode)
+ Medium external static pressure facilitates unit use with flexible
duct of varying lengths
23 q7x
86064 z!
Optional
CDXS
5 steps
CDKS
Standard
Standard
MKS/MXS
(cooling application only)
•
Slim Concealed Ceiling, Inverter Controlled Unit •
R-410A • CDKS/CDXS25,35,50,60CVMB
1
1
2
• Split - Sky Air • Indoor Units
