![Daikin CDXS25CVMB [5/23] Specifications](/views2/1778561/page5/bg5.png)
2
Specifications
NOMINAL CAPACITY and NOMINAL INPUT
For indoor units only:
INDOOR UNITS CDKS25CVMB CDKS35CVMB CDKS50CVMB CDKS60CVMB
NOMINAL INPUT Cooling
nominal
kW 0.100 0.100 0.140 0.160
For combination indoor + outdoor units (air cooled):
INDOOR UNITS CDKS25CVMB CDKS35CVMB CDKS50CVMB CDKS60CVMB
OUTDOOR UNITS 2MKS40/3MKS50B/4MKS58/75/90B 4MKS58/75/90B 4MKS75/90B
NOMINAL CAPACITY (2-3) Cooling (1)
min.∼nom.∼max.
kW
For more information, see chapter MKS-B
NOMINAL INPUT Cooling
min.∼nom.∼max.
kW
EER
ENERGY LABEL Cooling
ANNUAL ENERGY
CONSUMPTION
Cooling kWh
TECHNICAL SPECIFICATIONS
For indoor units only:
INDOOR UNITS CDKS25CVMB CDKS35CVMB CDKS50CVMB CDKS60CVMB
DIMENSIONS Unit H mm 200 200
W mm 900 1,100
D mm 620 620
WEIGHT Unit kg 25 27 30
SOUND LEVEL Sound pressure (Cooling)
(4)
high dB(A) 35 35 37 38
low dB(A) 31 31 33 34
super low dB(A) 29 29 31 32
Sound power (Cooling) (5) high dB(A) 53 53 55 56
FAN Air flow rate (Cooling) high m
3
/min 9.5 10.0 12.0 16.0
low m
3
/min 8.0 8.5 10.0 13.5
super low m
3
/min 6.7 7.0 8.4 11.2
Speed steps 5 steps, silent and auto
high rpm 1,090 1,110 1,270 1,280
medium rpm 1,010 1,040 1,180 1,160
low rpm 930 970 1,080 1,040
super low rpm 800 810 930 890
Type Sirocco fan
Motor output W 62 62 130 130
HEAT EXCHANGER Type ML fin, J 7Hi - XSS tube
Rows x stages x fin pitch mm 2 x 12 x 1.5 2 x 12 x 1.5 3 x 12 x 1.5 2 x 12 x 1.5
AIR FILTER Removable/washable/mildew proof
TEMPERATURE CONTROL Microprocessor control
PIPING CONNECTIONS liquid mm φ6.4
gas mm φ9.5 φ12.7
drain mm VP20 I.D. φ20
drain mm VP20 O.D. φ26
INSULATION MATERIAL
Heat insulation tape
Both liquid and gas pipes
For outdoor units Multi model application See chapter MKS-B
•
Slim Concealed Ceiling, Inverter Controlled Unit •
R-410A • CDKS/CDXS25,35,50,60CVMB
