![Daikin FVXS35BVMB [4/37] Specifications](/views2/1778598/page4/bg4.png)
ELECTRICAL SPECIFICATIONS
For indoor units only: FVKS25BVMB FVKS35BVMB FVKS50BVMB
CURRENT Nominal running current
cooling
A 0.14 0.14 0.14
Maximum running current
cooling
A −
For combination indoor units + outdoor units: FVKS25BVMB FVKS35BVMB FVKS50BVMB FVKS50BVMB
RKS25DVMB RKS35DVMB RKS50BVMB9 RS50BVMB
CURRENT Nominal running current
cooling
A −−7.5 7.5
Maximum running current
cooling
A
See chapter RKS-D/B: electrical data
See chapter RS-B: electrical
data
Starting current
cooling
A
For combination indoor units + outdoor units: FVKS25BVMB FVKS35BVMB FVKS50BVMB
3MKS50/4MKS58,75,90D 4MKS58,75,90D
CURRENT Nominal running current
cooling
A
See chapter MKS-D: electrical dataMaximum running current
cooling
A
Starting current
cooling
A
For indoor units only: FVKS25BVMB FVKS35BVMB FVKS50BVMB
POWER SUPPLY VM VM VM
NOMINAL DISTRIBUTION SYSTEM
VOLTAGE
Phase 1∼ 1∼ 1∼
Frequency Hz 50 50 50
Voltage V 230 230 230
NOTES
1 Nominal cooling capacities are based on: indoor temperature 27°CDB/19°CWB * outdoor temperature 35°CDB * refrigerant piping length: 7.5m *
level difference: 0m.
2 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
3 Units should be selected on nominal capacity. Maximum capacity is limited to peak periods.
4 The sound pressure level is measured via a microphone at a certain distance from the unit. For measuring conditions: please refer to item 6 of this
chapter.
5 The sound power level is an absolute value indicating the ’’power’’ which a sound source generates.
6 Energy label: scale from A (most efficient) to G (less efficient).
7 Annual energy consumption: based on average use of 500 running hours per year at full load (= nominal conditions)
•
Floor Standing, Inverter Controlled Unit • R-410A • FVK/XS25,35,50BVMB
2
Specifications
10
2
152
• Split - Sky Air • Indoor Units
