![Daikin FVXS35BVMB [6/37] Specifications](/views2/1778598/page6/bg6.png)
ELECTRICAL SPECIFICATIONS
For indoor units only: FVXS25BVMB FVXS35BVMB FVXS50BVMB
CURRENT Nominal running current
cooling/heating
A 0.14/0.14 0.14/0.14 0.26/0.32
Maximum running current
cooling/heating
A −
For combination indoor + outdoor units (air cooled): FVXS25BVMB FVXS35BVMB FVXS50BVMB
RXS25DVMB RXS35DVMB RXS50BVMB
CURRENT Nominal running current
cooling/heating
A −−7.5/8.2
Maximum running current
cooling/heating
A
See chapter RXS-D/B: electrical data
Starting current
cooling/heating
A
For combination indoor + outdoor units (air cooled): FVXS25BVMB FVXS35BVMB FVXS50BVMB
2MXS52/3MXS52/4MXS68,80D
CURRENT Nominal running current
cooling
A
See chapter MXS-D: electrical dataMaximum running current
cooling
A
Starting current
cooling
A
For indoor units only: FVXS25BVMB FVXS35BVMB FVXS50BVMB
POWER SUPPLY VM VM VM
NOMINAL DISTRIBUTION SYSTEM
VOLTAGE
Phase 1∼ 1∼ 1∼
Frequency Hz 50 50 50
Voltage V 230 230 230
NOTES
1 Nominal cooling capacities are based on: indoor temperature 27°CDB/19°CWB * outdoor temperature 35°CDB * refrigerant piping length: 7.5m *
level difference: 0m.
2
Nominal heating capacities are based on: indoor temperature 20°CDB * outdoor temperature 7°CDB/6°CWB * refrigerant piping length 7.5m
(horizontal) * level difference 0m.
3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
4 Units should be selected on nominal capacity. Maximum capacity is limited to peak periods.
5 The sound pressure level is measured via a microphone at a certain distance from the unit. For measuring conditions: please refer to item 6 of this
chapter.
6 The sound power level is an absolute value indicating the ’’power’’ which a sound source generates.
7 Energy label: scale from A (most efficient) to G (less efficient).
8 Annual energy consumption: based on average use of 500 running hours per year at full load (= nominal conditions)
•
Floor Standing, Inverter Controlled Unit • R-410A • FVK/XS25,35,50BVMB
2
Specifications
10
2
154
• Split - Sky Air • Indoor Units
