Daikin FVXS35BVMB [5/37] Specifications
![Daikin FVXS50BVMB [5/37] Specifications](/views2/1778598/page5/bg5.png)
NOMINAL CAPACITY and NOMINAL INPUT
For indoor units only:
INDOOR UNITS FVXS25BVMB FVXS35BVMB FVXS50BVMB
NOMINAL INPUT Cooling nominal kW 0.032 0.032 0.055
Heating nominal kW 0.032 0.032 0.070
For combination indoor + outdoor units (air cooled):
INDOOR UNITS FVXS25BVMB FVXS35BVMB FVXS50BVMB
OUTDOOR UNITS - PAIR APPLICATION RXS25DVMB RXS35DVMB RXS50BVMB
NOMINAL CAPACITY (3-4)
Cooling (1)
min.∼nom.∼max. kW −∼2.50∼− −∼3.50∼− 0.90∼4.80∼5.30
Heating (2)
min.∼nom.∼max. kW −∼3.40∼− −∼4.50∼− 0.90∼6.00∼7.70
NOMINAL INPUT
Cooling
min.∼nom.∼max. kW −∼0.70∼− −∼1.09∼− 0.45∼1.70∼2.35
Heating
min.∼nom.∼max. kW −∼0.90∼− −∼1.32∼− 0.31∼1.87∼2.60
EER Cooling 3.57 3.21 2.82
COP Heating 3.78 3.41 3.21
ENERGY LABEL Cooling A A C
Heating A B C
ANNUAL ENERGY
CONSUMPTION
Cooling kWh 350 545 850
OUTDOOR UNITS - MULTI APPLICATION 3MXS52/4MXS68,80D
For more information, see chapter MXS-D
TECHNICAL SPECIFICATIONS
For indoor units only:
INDOOR UNITS FVXS25BVMB FVXS35BVMB FVXS50BVMB
DIMENSIONS Unit H mm 600
W mm 650
D mm 195
WEIGHT Unit kg 13
COLOUR Unit Almond white
SOUND LEVEL Sound pressure
(cooling/heating) (5)
high dB(A) 38/38 39/39 44/45
low dB(A) 26/26 27/29 36/36
super low dB(A) 23/23 24/26 33/33
Sound power (cool/heat) (6) high dB(A) 54/* 55/* 56/57
FAN Air flow rate
(cool/heat)
high m
3
/min 8.1/9.2 8.3/9.2 10.8/13.2
low m
3
/min 4.3/4.8 4.3/5.0 7.7/9.4
super low m
3
/min 3.4/3.5 3.4/3.6 6.7/8.3
Speed (cooling/heating)
Upper/Lower
steps 5 steps, silent and auto
high rpm 1,100/1,180-1,120/1,200 1,120/1,200-1,160/1,240 1,290/1,380-1,390/1,510
medium rpm 900/960-930/1,020 930/990-960/1,040 1,140/1,220-1,220/1,330
low rpm 700/740-740/840 740/780-760/840 990/1,060-1,050/1,150
super low rpm 600/630-640/700 640/670-660/720 890/950-950/1,040
Type Cross flow fan
Motor output W 14+14
HEAT EXCHANGER Type Microprocessor control
Rows x stages x fin pitch mm 2 x 20 x 1.3 2 x 20 x 1.3 2 x 20 x 1.3
AIR FILTER Removable/washable/mildew proof
TEMPERATURE CONTROL Microcomputer control
PIPING CONNECTIONS liquid mm φ6.4
gas mm φ9.5 φ12.7
drain mm φ18.0 φ20.0
INSULATION MATERIAL Heat insulation tape Both liquid and gas pipes
For outdoor units Pair application See chapter RXS-D/B
Multi application See chapter MXS-D
•
Floor Standing, Inverter Controlled Unit • R-410A • FVK/XS25,35,50BVMB
2
Specifications
10
2
153
• Split - Sky Air • Indoor Units
