5.1 Setting the cutting depth (Figure 2)
Undo the locking screw for setting the cutting
depth (4).
Set the cutting depth in accordance with the scale
(a).
When cutting wood or plastic the selected cutting
depth should be a little larger than the material
thickness.
To prevent damage to underlying surfaces, the
cutting depth can be set exactly to the thickness
of the material. However, this will result in a
slightly unclean cut.
5.2 Extraction of dust and chips (Figure 3)
Connect your tool to an extraction unit or vacuum
cleaner. This will provide excellent extraction of chips
and dust from the workpiece.
The benefits are that you will protect both the
equipment and your own health. Your work area will
also be clean and safe.
Attach the adapter for the dust extraction system
(11) to the connection for the dust extraction
system (10).
You can then connect a suitable vacuum cleaner
(not supplied) to the dust extraction system
adapter (11).
5.3 Parallel stop (Figure 4/5)
The parallel stop (9) enables you to saw parallel
lines.
Loosen the locking screw for the parallel stop (8)
on the saw foot (6).
To assemble, slide the parallel stop (9) into the
guide (a) on the saw foot (6) (see Figure 4).
Set the required spacing and then tighten the
locking screw (8) again.
Using the parallel stop: Position the parallel stop
(9) flat on the edge of the workpiece and start the
cut.
6. Operation
6.1 Working with the mini hand-held circular saw
Always hold the mini hand-held circular saw
firmly.
Do not use force!
Push forwards gently and evenly with the mini
hand-held circular saw.
The waste piece should be on the left-hand side
of the mini hand-held circular saw so that the
wide section of the support bench supports its full
area.
If you are sawing down a line that has been
drawn, guide the mini hand-held circular saw
along the corresponding notch.
Clamp small pieces of wood securely before
sawing them. Never hold them with your hand.
Always follow the safety instructions. Wear safety
goggles.
Do not use defective saw blades or blades that
are cracked or broken.
Do not use any flanges / flange nuts whose bore
hole is larger or smaller than those in the saw
blade.
The saw blade must not be decelerated by hand
or by applying lateral pressure to the blade.
The soleplate must not jam and must return to its
initial position after the operation has been
completed.
Before you use the mini hand-held circular saw,
check the function of the soleplate with the mains
plug disconnected.
Before you use the machine, ensure that the
safety equipment such as the soleplate, flanges
and adjustment devices are in working order and
are correctly adjusted and secure.
You can connect a suitable dust extraction
system to the dust extraction adapter (11).
Ensure that the dust extraction system is safely
and correctly connected.
Important. Always pull out the power plug
before doing any work on the circular saw!
6.2 Using the mini hand-held circular saw
Select a suitable blade for the material you wish
to saw.
Check the condition and sharpness of the blade.
Set the cutting depth.
Pick up the tool and make sure that no air vents
are covered.
Switch on the tool and wait for a few seconds for
the blade to reach operating speed.
Press the locking button (3) and, applying a little
pressure, slowly lower the tool into the workpiece.
Push the saw forwards through the workpiece.
Never cut backwards!
Exert only little pressure on the tool when cutting.
The base plate must always lie flat on the
workpiece.
Before you start your sawing work on the
workpiece, you can raise the soleplate (6) with
the lever (5) as shown in Fig. 6. Starting the
sawing work is then easier when you want to
begin at the edge of a workpiece.
6.3 Switching ON/OFF (Fig. 1)
To switch on: Slide the ON/OFF switch (2) forwards
and hold.
To switch off: Release the ON/OFF switch (2)
